XDVD 1002CM PREPARATION
Table of Contents
Safety Information
Please read all instructions carefully before attempting to install or operate.
Due to its technical nature, it is highly recommended that your DUAL XDVD1002CM is installed by a professional installer or an
authorized dealer. This product is only for use in vehicles with 12VDC negative ground only.
Disconnect the vehicle battery's negative terminal before starting installation to prevent short circuits.
(consult a qualified technician for instructions if you are unsure)
Avoid installing the main unit where it would be subject to high temperatures, or where it would be subject to dust, dirt or
excessive vibration.
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVERS. NO USER-SERVICEABLE PARTS ARE INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.
2-3
3
4
5
6
7-8
9
10-11
12-13
14
15
16
17
18
18
19
Safety Information......................................
Before You Begin........................................
Package Contents.......................................
Wiring Diagram
.............................................
Mounting .................... . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Control Locations
......... ..................................
General Operation......................................
Setup Menu
................................. ................
Page 2
3
XDVD 1002CM PREPARATION
Before You Begin
Cautions
To prevent damage or injury:
1. Make sure to ground the unit securely to the vehicle chassis ground.
2. Do not remove the top cover of the unit.
3. Do not install the unit in a spot exposed to excessive heat or the possibility of water splashing.
4. Do not subject the unit to excessive shock.
5. When replacing a fuse, only use a new one with the prescribed rating. Using a fuse with the wrong rating may cause the
unit to malfunction.
6. To prevent short circuits when replacing a fuse, disconnect the wiring harness first.
7. Do not use any screws except the ones provided.
8. If you experience problems during installation, consult your nearest DUAL dealer.
9. To clean the monitor, wipe only with a dry silicone cloth or soft cloth. Do not use a stiff cloth, or volatile solvents such as
paint thinner and alcohol. They can scratch the surface of the panel and/or remove the printing.
10. When the temperature of the unit falls (as in winter), the liquid crystal inside the screen will become darker than usual.
Normal brightness will return after using the monitor for a while.
Additional Warnings
To prevent injury and/or fire, take the following precautions:
1. Ensure that the unit is securely installed.
2. When extending the ignition, battery or ground cables, make sure to use automotive-grade cables or other cables with
an area of 0.75mm (AWG 18) or more to prevent voltage drops and wire deterioration.
3. Do not touch the liquid crystal fluid if the LCD is damaged or broken. The liquid crystal fluid may be hazardous to your
health or fatal. If the liquid crystal fluid from the LCD contacts your body or clothing, wash it off with soap immediately.
DVD Region Management
Some DVD discs can be played only in certain playback modes according to the intentions of the software products. As this
player plays discs according to their intentions, some functions may not work as intended by you. Please be sure to read the
instructions provided with each disc. This player has been designed to play back the DVD software that has been encoded for
specific region areas. It cannot play back the DVD software encoded for other region areas than the region areas for which is
has been designed.
The XDVD1002CM will play discs labeled region 1 or "all".
DVD region codes are:
1. USA, Canada
2. Japan, Europe, South Africa, Middle East
3. Asia
4. Australia, New Zealand, Mexico, South America
5. Russia, India
6. China
