Page 1
IMPOR TANT SAFETY INSTR UCTIONS
safety-4v2.eps A ug 26/05
CA UTION :
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NO T REMO VE CO VER (OR BA CK).
NO USER SER VICEABLE PA RTS INSIDE .
REFER SER VICING TO QU ALIFIED
SER VICE PERSONNEL.
INSTR UCTIONS PERTA INING TO A
RISK OF FIRE, ELECTRIC SHOCK ,
OR INJUR Y TO PERSON S
Read Instructions
The Owner s Manualshould be read and understood
bef ore operation of y our unit. Please , save these instru c-
tions fo r future ref erence .
Pack aging
Keep the bo x and pac kaging mater ials , in case the unit
needs to be retur ned f or ser vice .
Warning
When using electr ic products , basic precautions should
alw ays be f ollowed, including the fo llow ing:
Po wer Sour ce s Your unit should be connected to a po wer source only of the vo ltage specified in the ow ners manual or as mark ed on the unit. This unit has a polar ized plug. Do not use with an e xtension cord or receptacle unless the plug can be fully inser ted. Precautions should be tak en so that the grounding scheme on the unit is not def eated.
Hazar ds Do not place this product on an unstab le car t, stand, tr ipod, brac ket or table. The product ma y fall, causing ser ious personal injur y and ser ious damage to the product. Use only with car t, stand, tr ipod, bra cke t, or table recommended by the manuf acturer or sold with the product. Follow the manuf acturer s instr uctions when installing the product and use mounting accessor ies recommended by the manuf acturer .
The apparatus should not be e xposed to dr
ipping or splashing w ater; no objects filled with liquids should be placed on the apparatus .
Te
rminals mar ked with the lightning bolt are hazardous liv e; the exter nal wir ing connected to these ter minals require installation by an instr ucted person or the use of ready made leads or cords .
No nak ed flame sources , such as lighted candle s, should be
placed on the apparatus .
Po wer Cor d The AC supply cord should be routed so that it is unlik ely that it will be damaged. If the AC supply cord is damaged DO NO T OPERATE THE UNIT .
ServiceThe unit should be ser viced only by qualified ser vice personnel.
A VIS: AFIN DE REDUIRE LES RISQUE DE CHOC ELECTRIQUE,
NENLEVEZ P AS LE COUVER T (OU LE P ANNEA U ARRIERE)
NE CONTIENT AUCUNE PIECEREP ARABLE PA R LUTILISA TEUR.
CONSULTEZ UN TECHNICIEN QU ALIFIE
POUR LENTRETIENT
INSTR UCTIONS RELA TIVES AU RISQUE
DE FEU , CHOC ÉLECTRIQUE, OU
BLESSURES AU X PERSONNES
Veuillez Lire le Manue l
Il contient des inf ormations qui de vraient êtres compr ises
av ant
lop ération de v otre appareil. Conser vez S.V.P. ces
instr uctions pour consultations ul
térieures.
Emballag e
Conserv ez la boite au cas ou lappareil de va it être
retour ner pour
réparation.
Attention:
Lors de lutilisation de produits é lectr ique , assurez-v ous
dadh é rer à des pr écautions de bases incluant celle qui
suiv ent:
AlimentationLappareil ne doit être branch é qu à une source dalimentation
correspondant au voltage sp écifi é dans le manuel ou tel qu indiqu é sur lappareil. Cet appareil est équip é dune pr ise dalimentation polar isée.
Ne pas utiliser cet appareil av ec un cordon de raccordement à moins quil soit possib le dinsérer compl ètement les trois lames. Des précautions doivent êtres prises afin deviter que le syst ème de mise Ã
la terre de lappareil ne soit désengag é.
RisqueNe pas placer cet appareil sur un char iot, un support, un tr épied ou une
tab le instab les. Lappareil pourrait tomber et blesser quelqu un ou subir
des dommages impor tants. Utiliser seulement un chariot, un suppor t,
un tr
é pied ou une tab le recommand és par le f abricant ou v endus avec
le produit. Suivre les instr uctions du fabricant pour installer lappareil et
utiliser les accessoires recommand é s par le f abricant.
Il con vient de ne pas placer sur
lappareil de sources de flammes nues, telles que des bougies allum ées.
Lappeil ne doit pas être e xpos é à des égouttements deau ou des éclaboussures et qu aucun objet rempli de liquide tel que des v ases
ne doit être plac é sur lappareil.
Les dispositifs marqu
és dune symbole déclair sont des par ties
dangereuses au toucher et que les câblages ex tér ieurs connect és Ã
ces dispositifs de connection ex tér ieure doiv ent être effectiv és par un opérateur form é ou en utilisant des cordons déjà pr épar és.
Cor don dAlimentatio n Évitez dendommager le cordon dalimentation. NUTILISEZ P AS LAPPAREIL si le cordon dalimentation est endommag é.
ServiceConsultez un technicien qualifi é pour lentretien de v otre appareil.
Page 2
1
The concept behind the design of the élite éXcursion1000 was
simple, -“create a powerful, yet highly mobile active stereo PA
and club system. Striking the right balance between portability
and presence, Yorkvilles designers selected a 15-inch bass driver
capable of handling a booming 650 watts and paired it with two 8-
inch/1-inch satellite loudspeakers delivering a crisp 150 watts a side; total output of over 950 watts. Thats enough
for the experienced club veteran, all in a single package (and its compact enough for one-night stands).
The heart of the élite éXcursion1000 is the active subwoofer unit. Housing the 15-inch driver, input section,
electronic crossover networks and the five integrated power amplifier modules that drive the entire éXcursion1000
system, this core unit is powered by a single AC line cord. To ensure trouble-free transport, the system comes
complete with a swivel caster dolly and Velcro-„¢ tie downs to allow for its nested satellite cabinets. With its
quick and convenient setup, teardown, and a minimum of cabling and connectivity to get in the way onstage, the
éXcursion1000 is an ideal solution wherever portability is an issue. And unlike competing PA system solutions,
the caster kit for the éXcursion1000 is fully detachable, eliminating caster buzz and rattle during performance.
The full-range satellite speakers are driven by the subwoofer through two 8M Speakon-„¢ fourline-cables
(included). This four-wire design allows the internal electronic crossover network to deliver an acoustically perfect
transition between subwoofer and satellite. Experienced design of the active bi-amp circuitry delivers 125 watts to
each of the 8-inch drivers and 25 watts to the 1-inch horns with precision, allowing unsurpassed efficiency and
clarity. Opto-limiter circuitry in the crossover network provides an unobtrusive and musical-sounding compression
that not only protects the speaker components, but provides balanced program reproduction from the satellite
cabinets. The entire system may be connected to any mono or stereo mixer source through either XLR or 1/4-inch
TRS balanced inputs. And true to Yorkvilles long-standing commitment to quality, the éXcursion1000 cabinets are
a rugged plywood construction -“ we never use fiberboard or composites.
A complete, self contained powered system with passive and active crossover networks, equalization, and
separate stereo and subwoofer level controls included, the élite éXcursion1000 is the ultimate in compact live/DJ
systems. This is a PA that is truly Plug and Play.
Features
- The ideal PA system for audiences of up to 300 people.
- Truly Plug and Play, all amplification and level controls are built in.
- Voiced for prerecorded applications as well as live sound reinforcement.
- XLR and 1/4-inch TRS balanced inputs connect easily to any mixer source.
- Active crossover networks with integrated power amplification create a seamless balance between subwoofer
and full-range, bi-amped stereo satellites.
- System nests together for easy transportation and storage.
- An ultra quiet, highly efficient, high output, low distortion, lightweight PA solution.
- Includes integrated bar handles and stand mount adaptors.
- Rugged plywood cabinet construction.
- Removable caster kit.
- Available in your choice of black carpet (EX1) and black Ultrathane (EX1B) painted finishes
P O W E R E D L O U D S P E A K E R S Y S T E M
