Page 1
The exclamation point within an equilatereal
tr iangle is intended to ale rt the user to the
presence of impor tant operating and
maintenance (ser vicing) instructions in the
literature accompan ying the appliance.
Le point de xclamation à lintér ieur dun triangle équilatéral
est prévu pour aler ter lutilisateur de la présence
dinstr uctions impor tantes dans la littérature accompag -
nant lappareil en ce qui concer ne lopération et la
maintenance de cet appareil. This lightning flash with arro whead symbol,
within an equilateral tr iangle, is intended to aler t
the user to the presence of uninsulated
dangerous v oltage within the products enclosure
that ma y be of sufficient magnitude to constitute a r isk of
electr ic shock to persons.
Ce symbole déclair avec tête de flèche dans un tr iangle
équilatéral est prévu pour aler ter lutilisateur de la présence
dun « v oltage dangereux » non-isolé à pro ximité de lenceinte
du produit qui pourrait être dampleur suffisante pour présente\
r
un r isque de choque électr ique.
IMPORTANT SAFETY INSTR UCTIONS
safety-4v5.eps - Apr il 3/2007
CAUTION : TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMO VE COVER (OR BA CK).
NO USER SER VICEABLE PARTS INSIDE.
REFER SER VICING TO QU ALIFIED
SER VICE PERSONNEL.
FOLLOW
ALL INSTR UCTIONS SUIVEZ TOUTES LES INSTR UCTIONS
Instructions per taining to a risk of fire,
electric shock , or injury to a per son
Read Instructions:
The Owners Manual should be read and
understood bef ore operation of y our unit. Please, save these instr uc-
tions f or future ref erence and heed all wa rnings .
Clean only with dr y cloth.
Packaging: Keep the bo x and packaging mater ials, in case the unit
needs to be retur ned for ser vice.
Warning: To reduce the r isk or fire or electr ic shock, do not e xpose
this apparatus to rain or moistur e. Do not use this apparatus near w ater!
Warning: When using electr ic products, basic precautions should
alw ays be f ollowed, including the f ollowing:
Power Sour cesYour unit should be connected to a po wer source only of the voltage specified in the
o wners manual or as ma rked on the unit. This unit has a polari zed plug. Do not use
with an e xtension cord or receptacle unless the plug can be fully inser ted. Precau-
tions should be tak en so that the grounding scheme on the unit is not def eated.
HazardsDo not place this product on an unstab le cart, stand, tr ipod, bracket or tabl e. The
product ma y fall, causing ser ious personal injury and serious damage to the product.
Use only with car t, stand, tripod, bracket, or tab le recommended by the manufacturer
or sold with the product. Follow the manuf acturers instructions when installing the
product and use mounting accessor ies recommended by the manufacturer.
The apparatus should not be e xposed to dripping or splashing w ater; no objects
filled with liquids should be placed on the apparatus .
Te rminals mark ed with the lightning bolt are hazardous live ; the e xternal wir ing
connected to these ter minals require installation by an instructed person or the use of
ready made leads or cords.
Ensure that proper v entilation is provided around the appliance. Do not install near
an y heat sources such as radiator s, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
No nak ed flame source s, such as lighted candle s, should be placed on the apparatus .
Power CordDo not def eat the saf ety purpose of the pola rized or grounding-type plug . A pola rized plug
has two b lades with one wider than the othe r. A grounding type plug has two b lades and a
third grounding prong . The wide b lade or the third prong are pro vided for your sa fety. If the
pro vided plug does not fit into y our outlet, consult an electrician for replacement of the
obsolete outlet . The AC supply cord should be routed so that it is unlik ely that it will be
damaged . If the AC supply cord is damaged DO NO T OPERATE THE UNIT .
Unplug this apparatus dur ing lightning storms or when unused f or long periods of time.
ServiceThe unit should be ser viced only by qualified service personnel.
AVIS: AFIN DE REDUIRE LES RISQUE DE CHOC
ELECTRIQUE, NENLEVEZ P AS LE COUVERT (OU LE
P ANNEA U ARRIERE)
NE CONTIENT A UCUNE PIECE
REP ARABLE P AR LUTILISA TEUR.
CONSUL TEZ UN TECHNICIEN QU ALIFIE
POUR L ENTRETIENT
Instructions relatives au risque de feu,
choc électrique, ou blessures aux per sonnes
V euillez Lire le Manuel:
Il contient des informations qui de vraient
êtres compr ises avant lopération de v otre appareil. Conservez .
Gardez S.V.P. ces instr uctions pour consultations ultér ieures et
obser vez tous les avertissement s.
Netto yez seulement av ec le tissu sec.
Emballage: Conservez la boite au cas ou lappareil de vait être
retour ner pour réparation.
A ver tissement: Pour réduire le r isque de feu ou la décharge
électr ique, n'exposez pas cet appareil à la pluie ou à l'humidité.
Nutilisez pas cet appareil près de leau!
Attention : Lors de lutilisation de produits électr ique, assurez-v ous
dadhérer à des précautions de bases incluant celle qui suiv ent:
AlimentationLappareil ne doit être branché quà une source dalime\
ntation correspondant au
v oltage spécifié dans le manuel ou tel quindiqué sur lap\
pareil . Cet appareil est
équipé dune pr ise dalimentation polar isée. Ne pas utiliser cet appareil av ec un
cordon de raccordement à moins quil soit possib le dinsérer complètement les trois
lames. Des précautions doiv ent êtres prises afin de viter que le système de mise à la
terre de lappareil ne soit désengagé.
RisqueNe pas placer cet appareil sur un char iot, un support, un trépied ou une tab le instables.
L appareil pourrait tomber et b lesser quelquun ou subir des dommages impor tants.
Utiliser seulement un char iot, un support, un trépied ou une tab le recommandés par le
fa br icant ou v endus avec le produit. Suivre les instr uctions du fabr icant pour installer
lappareil et utiliser les accessoires recommandés par le f abricant.
Il con vient de ne pas placer sur lappareil de sources de flammes nues , telles que
des bougies allumées.
Lappeil ne doit pas être e xposé à des égouttements deau ou des éclaboussures
et quaucun objet rempli de liquide tel que des v ases ne doit être placé sur lappareil.
Assurez que lappareil est f ourni de la propre v entilation. Ne procédez pas Ã
linstallation près de source de chaleur tels que radiateur s, registre de chaleur, fours
ou autres appareils (incluant les amplificateurs) qui produisent de la\
chaleur.
Les dispositifs marqués dune symbole déclair sont des par ties dangereuses
au toucher et que les câb lages extérieurs connectés à ces dispositifs de
connection extér ieure doiv ent être eff ectivés par un opérateur formé ou en utilisant
des cordons déjà préparé s.
Cordon dAlimentationNe pas enlev er le dispositif de sécur ité sur la prise polarisée ou la pr ise avec tige de
mise à la masse du cordon dalimentation. Une prise polar isée dispose de deux
lames dont une plus large que lautre. Une prise avec tige de mise à la masse
dispose de deux lames en plus dune troisième tige qui connecte à \
la masse. La
lame plus large ou la tige de mise à la masse est prévu pour v otre sécurité. La pr ise
murale est désuète si elle nest pas conçue pour accepter ce\
type de pr ise avec
dispositif de sécur ité. Dans ce cas, contactez un électr icien pour faire remplacer la
pr ise murale . Évitez dendommager le cordon dalimentation. NUTILISEZ PAS
L APP AREIL si le cordon dalimentation est endommagé.
Débranchez cet appareil durant les orages ou si inutilisé pendant de longues pér iodes.
ServiceConsultez un technicien qualifié pour lentretien de v otre appareil.
S2125A
Page 2
1
1. Power Switch and Indicator The green power LED illuminates when the power switch is turned to the On posi - tion and AC voltage is supplied.
2. Input Jacks This female-XLR / ¼-inch TRS combi-jack accepts either microphone or ¼-inch TRS patch cables. For best noise reduction, use balanced cables, however unbalanced ¼-inch TS cables can be used for unbalanced signal sources. Alternatively, a dynamic microphone can be directly connected here.
Note: Both ¼-inch and XLR inputs have identical functionality.
3. LinkThis XLR male connector can be used with a standard XLR cable ( XLR micro - phone cable for interconnecting E10Ps in a multi-speaker system. In Line Mode, (see Mic/Line Pushbutton below) up to ten (10) E10Ps can be interconnected without signal degradation.
Note: While it is possible to link E10Ps in Mic mode, it is recommended to use Line mode for best, noise-free performance. The number of E10Ps that can be linked in Mic mode depends on the degree of electrical interference present in the area and on the AC wiring.
E10P Powered SpeakerPower, superb sound quality, compactness, durable reliability and amazing versatility are at your fingertips. The E10P is an advanced, compact two-way powered speaker designed for a wide variety of pro-audio applications. Innovative processing is built-in to ensure optimum performance and clarity, including the ability to electronically reduce feedback. The lightweight, low-noise 300-Watt Class-D ampli - fier for the woofer is complemented by a two-tier 50-Watt amplifier for the horn (providing exceptionally clear and linear high-frequency response). An active crossover for the ampli - fiers ensures that the woofer and horn operate optimally; meanwhile, separate non-defeatable limiters protect those drivers from excessive peaks and over-powering. The drivers them - selves are from one of the worlds premier manufacturers offering an extended lifetime of smooth, powerful performance.
Versatility is the E10PBy designing the cabinet with an angled side and a stand adapter we made it possible for the E10P to be used either as part of your main system or as a stage monitor. For even more versatility, the E10P converts from a main/monitor system to a micro-PA. At the touch of a button it becomes capable of directly accepting a dynamic microphone. The 3-stage anti-feedback feature and bass/treble EQ make both system and micro-PA usage even more convenient. For use with a powered subwoofer, simply push another button on the E10P and all frequencies below 100 Hz are rolled off steeply. Result -“ no need for a crossover.
We are confident you will find the E10P a worthy mainstay for sound applications of all types and sizes.
The following section will help you to realize the E10P's full capabilities.
