NS-P8900 2 NS-P8900  SPECIFICATIONS NS-E8900 Type.....2-way 2-speaker acoustic suspension speaker system Magnetic shielding type Driver...................................... 8 cm (3-1/8") cone woofer x 1 2.5 cm (1") balanced dome tweeter x 1 Frequency Response (-10 dB) ................... 75 Hz to 20 kHz Impedance................................................................. 6 ohms Nominal Input Power................................................... 20 W Maximum Input Power.............................................. 100 W Sensitivity..................................................... 85 dB/2.83 V/m Crossover Frequency............................................... 12 kHz Input Terminal..................................... Screw / Banana type Dimensions (W X H X D)..................... 120 x 201 x 129 mm (4-3/4" x 7-15/16" x 5-1/16") Weight...................................................... 1.5 kg (3 lbs. 5 oz) Finish Walnut PVC ................................................... T, G models Cherry PVC .................................................... T, G models Accessories.................................. Speaker cable (10 m) x 2 NS-C8900 Type.....2-way 3-speaker acoustic suspension speaker system Magnetic shielding type Driver...................................... 8 cm (3-1/8") cone woofer x 2 2.5 cm (1") balanced dome tweeter x 1 Frequency Response (-10 dB) ................... 95 Hz to 20 kHz Impedance................................................................. 6 ohms Nominal Input Power................................................... 30 W Maximum Input Power.............................................. 125 W Sensitivity..................................................... 89 dB/2.83 V/m Crossover Frequency............................................... 12 kHz Input Terminal..................................... Screw / Banana type Dimensions (W X H X D)..................... 360 x 120 x 128 mm (14-3/16" x 4-3/4" x 5-1/16") Weight...................................................... 2.5 kg (5 lbs. 8 oz) Finish Walnut PVC ................................................... T, G models Cherry PVC .................................................... T, G models Accessories.................................... Speaker cable (4 m) x 1 Fastener x 2 * Specifications are subject to change without notice due to product improvements. T ..........Chinese model G......European model NETWORK CIRCUIT DIAGRAMS NS-E8900 TERMINAL RE BL WOOFER BE BL TWEETER C-1 1uF WOOFER TERMINAL RE BL TWEETER BE BL C-1 1uF WOOFER RE BL NS-C8900

Page 2

ABCDE 1 2 3 4 5 6 7 3 NS-P8900 NS-P8900 NS-E8900 REPLACEMENT PARTS LIST ñ ø þþþ÷÷    çî ô ÿ÷÷ ü÷ÿ÷÷ô  ÷ý ñ ø þþþø÷    çî ô ÿ÷÷  ü÷ÿ÷÷ô  ÷þ ñ ù þþýý÷  ç çî ô ÿ÷÷ ü÷ÿ÷÷ô  ÷ù
