SERVICE MANUAL
.FRONT PANEL
YAMAHA
JX saunas
@5- O@
.CONTENTS
SPECIFICATIONS ....................... 1 PRINTED CIRCUIT BOARD ............... . 3
GENERAL ADJUSTMENT AND CHECK ........ 1 SCHEMATIC DIAGRAM .................. . 4
BLOCK DIAGRAM ...................... 3
SINCE 1857
YAMAHA
NIPPON GAKK .. LTD, HAMAMATSU.JD~PAN
005520 Prmled In Japan 6.82 In@ wk
JXSSB
ISPECIFICA
TIONS
OUTPUT POWER
INPUT SENSIVITY (at
30W (89 T.H.D. 3%)
1 kHz)
POWE H CONSUMPTION
US & Canadian models 40W 0.5A
General model 65W
120V ACfixed,or110, 130, 220 or
E0. VOL HIGH >39dBl 9mv) POWER SOURCE
VOLUME} "3 Low -27dB (35mV) 240v AC selectable,50/60Hz
INPUT IMPEDANCE HIGH 34o kn DIMENSIONS 544 x 695 x 300 mm
LOW so kn (WxHxD) (21-3/8" x 27-3/8" x 11-7/8")
-55dB (VOLUME ->mIn.I WEIGHT 23.5 kg (51 lbs.)
NOISE
-35dB (VOLUME 9max.)
HEADPHONE JACK
SPEAKE R
-8dB (03V) @ 30W 8n
YAMAHA JA3808 (389m) x1
Specifica
(MB is referenced to 0.775 V HMS.
tian subject to change without notice.
.GENERAL ADJUSTMENT AND CHECK SPECIFICATIONS
For the measurements, use an oscillator with an output impedance of below 1kfl, an oscilloscope and an AC voltmeter/
dB meter with an input impedance of over IOOkQ.
I. GENERAL ADJUSTMENT
Oldling Current Adjustment
Adjust the pot (65000) so that the voltage across the
terminals TP1 (+) and E (-) on PM circuit board is
set to 5mV i 1mV.
*When readjusting all over again (e.g. when replacing
the power transistor), make sure to turn the pot full
counterclockwise.
Idling Current
5mV t 1mV
__l
l
r.
l
-'I(-l @]
HI -| TME El]
5
TP1 @ E] D
IDLE ADJ. TF3 CE:
El
TP2
HIGH LOW u u U U u
LINPUT-l VOLUME MIDDLE TREBLE BASS COMPRESSOR HEADPHONE
Fig.1
