Safeguards
Please take the time to read this Owners Manual.
The following guidelines are designed to assure a safe and
properly installed Xtant Mobile Audio System. All Xtant amplifiers and accessories are intended to be installed by a certified
professional mobile audio installation specialist. It is the recommendation of
Xtant Technologies that your new Xtant product(s) and all of your mobile
audio products be installed by your Authorized Xtant Select Dealer. Wiring Requirements All Xtant A-Series amplifiers have minimum wire gauge requirements for:
Power - 4 gauge
Ground - 4 gauge
Speaker cables - 12 gauge. Fusing Requirements A Series Amplifiers are not fuse protected! For safety, an outboard fuse may be
added close to the amplifier. A fuse mustbe installed in-line with the power wire
at the battery, no further than 18 from battery. For fuse requirements refer to
pages 5 and 6 of this manual. In the case of a muti-amp system, use a fuse value
equal to the combined value of all (system amplifiers) on-board power fuses. Water and Moisture Install all Xtant amplifiers and accessories in a location free of moisture or
exposure to water.
3
English
Technical Services Our customers satisfaction is our purpose. You represent our present and our
future. It is our goal to create and nurture relationships based upon trust and
respect. This commitment is not taken lightly or just for today; it is our way of
doing business. We believe there is no other way.
Xtants policies and procedures are designed, in the event of a problem, to
minimize the amount of your down-time and inconvenience. It is our
commitment to service and return such product in no more than two (2)
working days from the time Xtant receives the equipment. Please consider
weekends or holidays (which may fall within the time period) when estimating
the return date of serviced product.
For technical assistance and information regarding products and/or installation,
please contact Xtants Customer Relations Department from 8:00 am to 5:00 pm
Monday thru Friday at:
Phone: (888) 449-8268
Fax:(602) 431 8600
Welcome
Thank you for your purchase of an Xtant amplifier. The concept
is simple -“ a more carefully engineered amplifier will produce
superior sound. That is our passion -“ to exceed your expectation
of the automotive llistening experience. We are driven by it.
To accomplish this lofty goal, it takes the finest engineering
talent in the business, combined with a dedication to superior
materials. And we add in a multitude of features, unique
cosmetics, and creative system integration.
Xtant products are only available through the finest, most
highly-specialized mobile audio retailers. Your Xtant Select
Dealer was chosen because of their passion for excellence
and their commitment to expanding their expertise. Please
remember, exceptional audio requires professional
installation. Your Xtant Dealer will optimize your system and
your level of satisfaction.
Whether you are deeply involved in autosound
competition, or a privately passionate connoisseur of fine
music, we salute you, and appreciate your investment in
quality mobile audio.
We look forward to a long and lasting relationship!
Welcome to Xtant!
