Xtant 2 2 4 4 owners manual

Page 1

xtant.com Xtant2.2/Xtant4.4 Amplifier Owners Manual WELCOME TO XTANT Congratulations on your Xtant amplifier purchase. The concept is simple-a more carefully engi - neered amplifier to produce superior sound. That is our passion-to exceed your expectation of the automotive listening experience. We are driven by it. To accomplish this lofty goal, it takes the finest engineering talent in the business, combined with a dedication to superior materials. We add in a multitude of features, unique cosmetics, and creative system integration. Xtant products are only available through the finest, most highly-specialized mobile audio retailers. Your authorized Xtant retailer was chosen because of their passion for excellence and their com - mitment to expanding their expertise. Please remember, exceptional audio requires professional installation. Your Xtant retailer will optimize your system to meet your personal tastes. With your purchase of Xtant mobile audio, you publicly confirm your status as a connoisseur of fine music. We salute you and welcome you to our family. Welcome to Xtant! INSTALLING YOUR XTANT AMPLIFIER All Xtant amplifiers and accessories are intended to be installed by an Xtant-certified professional mobile audio installation specialist. It is the recommendation of Xtant Technologies that your new Xtant product(s) and all of your mobile audio products be installed by your Authorized Xtant retailer. In the event you decide to install your new Xtant product(s), please take the time to read this Owners Manual in its entirety. Installation and/or use of your amplifier in applications or methods other than those specified in your Xtant amplifier owners manual may result in a reduction of the overall performance capability of the amplifier. Any such installation or usage renders the prod - uct warranty void. The following guidelines are designed to assure a safe and properly installed Xtant Mobile Audio System. We strongly recommend that you acquaint yourself with your Xtant amplifiers available features and spend some time designing a system most suitable for you. Consider the components you have now, those you have and plan to upgrade, and those you plan to add in the future. FRANÇAIS PG 11 ESPAÑOL PG 19 DEUTSCH PG 27

Page 2

SPECIFICATIONS XTANT2.2 XTANT4.4 Frequency Response: 20 Hz-20 kHz ±1dB 20 Hz-20 kHz ±1dB Number of Channels: 2 4 Watts per Channel @ 4 Ω: 2 x 50 4 x 50 Watts per Channel @ 2 Ω: 2 x 100 4 x 100 Bridged Mono @ 4 Ω: 1 x 200 2 x 200 Recommended Load: -��2Ω Stereo / -��4Ω Bridged -��2Ω Stereo / -��4Ω Bridged Distortion (THD): -��.1% -��.2% 20 Hz-20 kHz at rated power, all channels driven 4 Ω Signal to Noise Ratio: -�� 100dB -�� 100dB A-weighted in 20 kHz noise bandwidth @ 1 volt sensitivity Damping Factor: -�� 200 @ 100 Hz -�� 100 @ 100 Hz with 4 Ω load with 4 Ω load Input Sensitivity: Unbalanced 100 mV-8.5 V RMS 100 mV-8.5 V RMS Balanced 200 mV-17 V RMS 200 mV-17 V RMS Input to Line Output Gain: 0dB 0dB On-Board Crossover: HP: 12dB/Oct, Front-HP:12dB/Oct, 40-120 Hz 40-120 Hz LP: 24dB/Oct Mono, Rear-HP: 12dB/Oct, 40-120 Hz or LP:24dB Mono LP, 40-120 Hz Balanced Line: On Board On Board Power Supply: Fully Regulated, PWM Fully Regulated, PWM Operational Voltage: 10-16 Volts 10-16 Volts Fusing Requirement: 30 Amp 60 Amp Size (L x W x H): 11 11-��16" x 9 1-��16" x 2" 15 9-��16" x 91-��16" x 2 " 297mm x 230mm x 51mm 395mm x 230mm x 51mm A.R.C.: 0-15dB Level Adjustment 0-15dB Level Adjustment Bass Boost: 0-12dB @ 45 Hz 0-12dB @ 45 Hz Warranty: Limited 4 Year Parts Limited 4 Year Parts and Labor and Labor 3
