Mini Modul
WEGA .HlFl-STEBEO-CASSETTEN-DECK 6210
Kundendienstanleitung
Service Manual
11/80
INHALT
Technische Daten
Teil 1 Blockschaltbild
Pegeldiagramm
Teil 2 Abgleich
Teil 3 Schaltbilder
Halbleiteranschlfisse
Teil 4 Explosionsdarstellungen
Teil 5 Ersatzteiiliste
Seite/ Pa ge
CONTENTS
Specifications
Section 1 Block diagram
Level Diagram
Section 2 Adjustments
Section 3 Diagrams
Semiconductors '
Section 4 Exploded views
Section 5 Spare Parts list
