IC-100 Programmer's Guide - revised September 1999 Page 1
Overview
IC-100 security installations often require integration with touch-screen control systems, graphic
annunciator panels and camera controllers. TOA offers two options for meeting this requirement:
1. The DI-100 and DI-110 interface products offer a hardware solution-they provide the call
LED outputs and select switch inputs required for graphic annunciator panels. They also
provide relay outputs for camera switcher integration. Using this off-the-shelf method requires
no knowledge of computer programming or serial communication.
2. Integrators using a microprocessor-based product (usually a PC or PLC) as their integrated
system's control center, often prefer direct control and monitoring of IC-100 control station
activity through the IC-100's integral serial port. Using Remote Control and Monitoring
eliminates the need for installing DI-100s and DI-110s and elevates the programmer's level of
control.
This document targets programmers who need an understanding of how they can remotely
control and monitor the IC-100 by communicating through its RS-232 port. The following
document sections provide the details:
Connecting to the IC-100
Communicating with the IC-100
Using the Remote Dial Command
Monitoring Control Station Activity
Interpreting DI-100 Call LED Data
Appendix A Control Station Display Data Listing
Appendix B Extended ASCII Character Codes
