Page 1
Thule AudioApS
H¿rk¾r 14
2730 Herlev
Denmark
Tel
+45 44 94 60 00
Fax +45 44 94 68 80
thule-audio@email.dk
www.thule-audio.com
[ be surprised about the difference ]
As you can see from the above productdescriptions,we have taken every possible step to give
you perfectaudio experiences:whether you wantto listen to your favourite
CD or the radio
news,Thule Audio will make your experience better.The Spirit
CD players and the tuner are
designed to match our amplifier products perfectly,both with regards to their exterior designs
and their sonic performance.So,to really enjoy the unparalelled musicality of our products,
combine
CD 100, CD 150 Bor TU100 with any of our Spiritor Space amplifiers.
A nice bonus is thatnone of this will costyou a fortune.The price/quality relationship of our
products is outstanding and we highly doubtthatyou will find better
CD players in the price
range of
CD100 and CD150 B.You will be surprised whatquality audio products can do.
[ technical specifications ]
Connections: CD 150 BCD 100 TU 100
Unbalanced output:2.2V+/-0.2V2.2V+/-0.2V500mV
Balanced output:4.4V+/-0.4V--
Digital output:0.5V / 75ohms0.5V / 75ohms-
Technical Quality: CD 150 BCD 100 TU 100
THD,1kHz,0dB ( 20-20k Hz BW ):<0.003%<0.0035%<0.1% (22.5kHz dev)
THD,1kHz,-60dB ( 20-20k Hz BW ):<0.4%<0.4%-
S/N ( 20-20k Hz BW ):>96/98 dBA>96dBA72dB (1mV HF)
Linearity,-80dB:<+/-0.2dB<+/-0.2dB-
Frequency response,20kHz:<- 0.7dB<-0.7dB-0.5dB (15kHz)
General: CD 100 CD 150 BTU 100
Size ( W x H x D ),weight:420 x 80 x 280 mm7kg6kg
Max.power consumption:15W15W12W
THULE AUDIO reserve the rightto alter design and specifications withoutnotice.
All functions can
be operated by the
system remote.
TU100 / IA150 B/ CD150 B
