Page 1
Instruction manual
2
Dear customer!
Thank you for purchasing our product. For safety, it is strongly recommended to read
this manual carefully before connecting, operating and/or adjusting the \уproduct and keep
the manual for reference in future.
Description
1. Telescopic FM antenna
2. USB port
3. VOL+/AL1 button
4. VOL-/AL2 button
5. FUNCTION/MODE button
6. Top: PLAY/PAUSE button
Bottom: MUTE/SNOOZE button
Left:
(SKIP-) button
Right:
(SKIP+) button 7. LCD display
8. Handle
9. SD card slot
10. PRESET+/ALBUM+ button
11. PRESET-/ALBUM- button
12. POWER/SLEEP button
Not indicated:
Battery compartment (bottom panel)
Headphone socket (back panel)
Power cord socket (back panel)
AUX input (back panel)
PRE
PRE
1
8
9
10
11
12
2
3
4
5
6
7
Page 2
Instruction manual
3
- Close the battery compartment cover.
AC operation
- Before the first connecting of the appliance
check that voltage indicated on the rating label
corresponds the mains voltage in your home.
- Plug the corresponding end of cord into
the AC socket on the rear of the set.
- Insert the plug into power supply.
Caution:
- When the set is only used with AC or is
not used for 2 weeks or more, please remove
the batteries, to avoid damage to the set from
leakage of batteries.
- Always switch off the unit when not in use.
- Always unplug the appliance from power
supply, when no use long time.
General operations
Power on/off
Press POWER button to switch on the unit.
Press and hold this button to switch off the
unit.
Electronic volume control
- This unit uses an electronic volume control.
To increase or decrease the loudness of unit,
press respectively VOL+/VOL- buttons.
Automatic power off (sleep) function
- This set has a special sleep timer function
which can automatically switch off the unit.
- At any time while the unit is operating,
press SLEEP button repeatedly to choose the
automatic power off time: 90 min => 80 min =>
70 min => 60 min => 50 min => 40 min => 30
min => 20 min => 10 min => OFF.
Mute
Press MUTE button to mute the sound.
Press the button again or adjust the volume to
resume sound output.
Utilization of the product
If you want to dispose of this product, do not
mix it with general household waste. There is a
separate collection system for used electronic
products in accordance with legislation that
requires proper treatment, recovery and
recycling.
Please contact your local authorities for
the correct method of disposal. By doing so,
you will ensure that your disposed product
undergoes the necessary treatment, recovery
and recycling and thus prevent potential
negative effects on the environment and
human health.
Important safeguards
- Attention: The owners manual contains
important operating and maintenance
instructions. For your safety, it is necessary to
refer to the manual.
- Dangerous voltage: Uninsulated
dangerous voltage that may be of sufficient
magnitude to constitute a risk of electrical
shock to persons is present within this product
enclosure.
- Caution: To reduce the risk of electric
shock, do not dismantle the body. Prefer
servicing to qualified service personnel. Do not
use the unit in places where it can be exposed
to water, moisture and dust. Make sure that
pins or other foreign objects do not get inside
the unit; they may cause malfunctions, or
create safety hazards such as electrical shock.
Power supply
Battery operation
- Open the battery compartment cover.
- Insert 4 x UM-2/LR14 batteries. Please
observe correct battery polarities or the set will
not work.
