Page 1
Instruction manual
2
Dear customerй
Thank you for purchasing our product. For safety, it is strongly recommended to read
this manual carefully before connecting, operating and/or adjusting the product and keep
the manual for reference in future.
Description
Front panel Back panel
1. Handle
2. LCD display
3. Speaker
4. Power switch
5. USB port
6. AUX input
7. LED indicator
8. SD/MMC card slot
9. DC adapter in
10. PLAY/PAUSE (
) button
11. PREVIOUS (
) button
12. NEXT (
) button
13. M button
Not indicated: battery compartment
(bottom of the unit)
45
6
789
1011 12
13
1
2
3
Page 2
Instruction manual
3
Important safeguards
- The instruction manual contains important
operating and maintenance instructions. For
your safety, it is necessary to refer to the
manual. Keep the manual for use in future.
- Do not hit or drop the unit.
- Do not expose the unit to vibration, direct
sunlight, too high or low temperature or humidity.
- Do not disassemble the unit yourself.
Refer servicing to qualified service personnel.
- When the battery is exhausted, it should
be removed from the set to prevent leakage.
Power supply
Battery power
- Open the battery compartment cover.
Insert the 5C 3.7V lithium battery. Please
observe correct battery polarity or the unit
will not work. Close the battery compartment
cover.
- When the battery power gets low, you
should plug in the charger into the appropriate
slot on the back of the unit.
Charger
- Plug the supplied charger into the micro
USB port on the back of the unit. Connect
the power cord to a household mains outlet.
The LED indicator will light red, meaning the
charging is in process. After 3-5 hours the
indicator will turn off, meaning the battery is
fully charged.
- Charger or adaptor can along with battery
charger be used as power supply, but the
volume should not exceed 24 levels. If volume
is higher than 24 (while battery not inserted)
the unit can switch off automatically.
- Always remember to disconnect the power
cord from the mains before disconnecting it
from the unit.
- Disconnect the power cord from the mains
when not in use.
Remote control
1. POWER/STANDBY button
2. EQ/SAVE button
3. VOL+/VOL- buttons
4. REPEAT button
5. FM SCAN button
6. MODE button
7. LIGHT button
8. PLAY/PAUSE button
9. PREVIOUS/NEXT button
10. Number buttons
Utilization of the product
If you want to dispose of this product, do not
mix it with general household waste. There is a
separate collection system for used electronic
products in accordance with legislation that
requires proper treatment, recovery and
recycling.
Please contact your local authorities for
the correct method of disposal. By doing so,
you will ensure that your disposed product
undergoes the necessary treatment, recovery
and recycling and thus prevent potential
negative effects on the environment and
human health.
1
2
34
5
6
7
8
9
10
Page 11
Руководство по экспл\Ёуатации
12
Технические ха-акте-истики
FM-диапазон Гbадиочастот87,5 - 108 MГц
ПоддеГbжка носителей USB/SD/MMC
Входное напГbяжение адаптеГbа AC100-240 ~ 50/60 Гц
Выходное напГbяжение адаптеГbа 5 В постоянного тока / 600 ГfА
НоГfинальная потГbебляеГfГВая Гfощность от батаГbеи: 4,8 Вт от адаптеГbа: 3 Вт
Выходная Гfощность 2 х 1,5 Вт
АккуГfулятоГbная батаГbея 3,7 В/1000 ГfАч (Литиевая)
BluetoothBluetooth V2.1+EDR (длина ключа 4-128
бит), ГfаксиГfальная
дальность действия без усиления и Гbе-
тГbанслятоГbов 10 ГfетГbов
частота, МГц 2400 - 2483,5
Гfощность, ГfВт 10
пГbотокол 802.15.4
Вес нетто/бГbутто 0,69 кг / 1,05 кг
РазГfеГbы устГbойства 140 ГfГf x 140 ГfГf x 140 ГfГf
Технические хаГbактеГbистики и функции Гfогут быть изГfенены заводоГfГВ-изготовителеГf
без пГbедваГbительного увеГВдоГfления в связи с постоянныГf усовеГbшенствованиеГf данного
устГbойства.
П-оизведено:
ШЭНЬЧЖЭНЬ СИТИ ВИКТОРИ
ПРОСПЕР ИН БИЗНЕС СОРС
ИМПОРТ ЭН- ЭКСПОРТ ЛТ-.
11Ф, -ЗИНАНЬБИЛ-ИНГ, ВЭН-ЗИНАНЬРОУ-,
ЛУОХУ, ШЭНЬЧЖЭНЬ, КИТАЙ
Под конт-олем «ТЕХНО ЭЛЕКТР\ЁИК ЛИМИТЕ\f»
Сделано в Китае
TF-1634UB_IM_03
