3 Caution for AC Main Lead

(For United Kingdom)

(EB" area code model only)

For yourisafety, please read the following text careful-
ly. .

This appliance is supplied with a moulded three pin
mains plug for your safety and convenience.

A 5-ampere fuse is fitted in this plug.

Should the fuse need to be replaced please ensure
that the replacement fuse has a rating of 5-ampere
and that it is approved by ASTA or BSI to BS1362.
Check forithe ASTA mark ® or the BSI mark @ on
the body of the fuse.

If the plug contains a removable fuse cover you must
ensure that it is refitted when the fuse is replaced.

If you lose the fuse cover the plug must not be used
until a replacement cover is obtained.

A replacement fuse cover can be purchased from
your local dealer.

CAUTION!

IF THE FITTED MOULDED PLUG IS UNSUIT-
ABLE FOR THE SOCKET OUTLET IN YOUR
HOMEAII'HEN THE FUSE SHOULD BE RE-
MOVED AND THE PLUG CUT OFF AND DIS-
POSED OF SAFELY.

THERE IS A DANGER OF SEVERE ELECTRI-
CAL SHOCK IF THE CUT OFF PLUG IS IN-
SERTED INTO ANY 13-AMPERE SOCKET.

._ E
If a nemIlplIJg is to be fitted please observe the wiring
code aslshbwn below.

lf in anydoubt please consult a qualified electrician.

IMPORTANT
The wires in this mains lead are coloured in accor-
dance With the following code:

Blue: Neutral, Brown: Live.

As these colours may not correspond with the coloured
markings identifying the terminals in your plug, proceed
as followszt

The wire which is coloured Blue must be connected to
the terminal which is marked with the letter N or col-
oured Black or Blue.

The wire which is coloured Brown must be connected
to the terminal which is marked with the letter L or co-
loured Brown or Red.

WARNING: DO NOT CONNECT EITHER WIRE TO
THE EARTH TERMINAL WHICH IS MARKED WITH
THE LE'I'I'ER E, BY THE EARTH SYMBOL J7- OR CO-
LOUREDGREENORGREEN/YELLOW.

THIS PLUG IS NOT WATERPROOFéKEEP DRY.

Before use
Remove the connector cover.

How to replace the fuse

The location of the fuse differ according to the type of
AC mains plug (figures A and B). Confirm the AC
mains plug fitted and follow the instructions below.
Illustrations may differ from actual AC mains plug.

1. Open the fuse cover with a screwdriver.

Figure A

2. Replace the fuse and close or attach the fuse cover.

Figure A

Fuse
(5 ampere)

Figure B

Fuse
wampmm
