We want to thank you for selecting this product and to
welcome you to the growing family of satisfied
Technics product owners around
the world.
We feel certain you will get maximum enjoyment from this
new addition to your home.
Please read these operating instructions carefully,
and be sure to keep them handy for convenient
reference.
Contents
- For United Kingdom 2
-Suggestions for Safety 3
-Accessories 4
-Connections 4
-Front Panel Controls and Functions 5
-Operation 7
-Troubleshooting Guide 11
-Maintenance 11
-Technical Specifications 11
For United Kingdom
("EB" area code model only)
The "EB" indication is shown on the serial number tag. Important
THE WIRES IN THIS MAINS LEAD ARE COLOURED IN ACCOR- DANCE WITH THE FOLLOWING CODE.
BLUE: NEUTRAL
BROWN: LIVE
This apparatus was produced to BS 800.
As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug proceed as follows. The wire which is coloured BLUE
must
be connected to the terminal which is marked with the letter N or coloured BLACK.The wire which is coloured BROWN must be connected to the
terminal which is marked with the letter L or coloured RED.
Under
no circumstances must either of the above wires be
connected to the earth terminal of a three pin plug.
-2-
Page 2
Suggestions for Safety -˛ *'
- Use a standard AC wall outlet 1. Use from an AC power source of high voltage, such as for
an air conditioner, is very dangerous.
There is the possibility that a fire might be caused by making
such a connection.
2. A DC power source cannot be used. Be sure to check the power source carefully, especially on a
ship or other place where DC is used.
- Grasp the plug when disconnecting the power
supply cord
1. Wet hands are dangerous.
A dangerous electric shock may result if the plug is touched by
wet hands. 2. Never place heavy items on top of the power supply cord, and never force it to bend sharply.
- AC outlet on rear panel
(not
equipped for some countries) 1. Any equipment connected here should have the specified power consumption or less.
This outlet
is exclusively for the connection of other audio
equipment, such as a tape deck. Be sure the power consump-
tion does
not exceed the wattage specified near the AC outlet. 2. Never connect other electrical appliances, such as an iron or toaster.
If appliance with a large power consumption is connected, an
accident might occur as a result of overheating.
- Place the unit where it will be well ventilated Place this unit at least 10 cm (4") away from wall surfaces, etc.
- Avoid places such as the following:
In direct sunlight or in other places where the temperature is high.In places where there is excessive vibration or humidity. Such conditions might damage the cabinet and/or other compo-
nent parts and thereby shorten the unit's service life.
CAUTION!
DO NOT INSTALL OR PLACE THIS UNIT IN A BOOK-
CASE,
BUILT IN CABINET OR IN ANOTHER CONFINED SPACE IN ORDER TO KEEP WELL VENTILATED CON-
DITION. ENSURE THAT CURTAINS AND ANY OTHER MATERIALS DO NOT OBSTRUCT THE VENTILATION CONDITION TO PREVENT RISK OF ELECTRIC SHOCK
OR FIRE HAZARD DUE TO OVERHEATING.
.
- Be sure to place the unit on a flat, level surface If the surface is inclined, a malfunction may result.
- Never attempt to repair or reconstruct this unit A serious electric shock might occur if this unit is repaired, disassembled or reconstructed by unauthorized persons, or if the
internal parts are accidentally touched.
- Take particular care if children are present Never permit children to put anything, especially metal, inside this unit. A serious electric shock or malfunction could occur if articles
such as coins, needles, screwdrivers, etc. are inserted through the ventilation holes, etc. of this unit.
- If water is spilled on the unit Be extremely careful if water is spilled on the unit, because a fire or serious electric shock might occur. Immediately disconnect the
power cord plug, and consult with your dealer.
- Avoid spray-type insecticidesInsecticides might cause cracks or "cloudiness" in the cabinet and
plastic parts of this unit. The gas used in such sprays might, moreover, be ignited suddenly.
- Never use alcohol or paint thinner These and similar chemicals should never be used, because they
might cause flaking
or cloudiness of the cabinet finish.
- Disconnect the power supply cord if the unit
will not be used for a long time If the unit is left for a long time with the power ON, this will not only
shorten
its useful operation life, but may also cause other troubles.
- If trouble occurs
If, during operation, the sound is interrupted or indicators no longer
illuminate, or if abnormal odor or smoke is detected, immediately
disconnect the power cord plug, and contact your dealer or an
Authorized Service Center.
