Technics SAGX 190 Service Manual

Page 1

ORDER NO. M09504018A2

Service Manual

ReceWer
AV Control Stereo Receiver
S A- G X 1 9 0
Colour
(K) Black Type
Area
323:;10; Area Colour
(EB) Great Britain. (K)

. [ Please file and use thls manual together with the service manual for Model No. SA-GX170, Order No. AD940511968. J

Note: -This service manual is provided to indicate the main differences between the original model No.
SA-GX170 (EB) and the subsequent model No. SA-GIX190 (EB).

CHANGES

ICHANGE IN REPLACEMENT PARTS LIST (SA-GX170 Service Manual pages 38~44-)

. Notes: - Mentioned in this parts list is only those different from Model No. SA-GX170 (EB).
All other parts are the same as for SA-GX170 (EB).
0 Important safety notice:
Components identified by A mark have special characteristics important for safety.
Furthermore, special parts which have purposes of fire retardant (reslstors), high-quality sound (capacitors),
low- noise (resistors), etc. are used
When replacing any of components, be sure to use only manufacturers specified parts shown in the

parts list.
. [M] Indicates in Remarks columns parts that are supplied by MESA.
. Change of Part No.
Ref. No. Part Name a Description Remarks
SAvGX170 (EB) + SA-GX190 (EB) *
INTEGRATED CIRCUIT(S)
IC451 AN6558-FSG AN6558-F PHONO EQ AMP [M]
|0901 LCBA01265481 LCBAO1-265524 , MIGROCOMPUTER
TRANSISTOR(S) .
0107, 108 2803311ARSTA _ 2503311AR TRANSISTOR
0191 - 193 2363311ARSTA 2563311AR TRANSISTOR
Q505, 506 2803311AIRTA 2803311AR TRANSISTOR
0601 -603 ZSA1309AIRTA 23A1309A-R TRANSISTOR
0651, 652 25A1309AIRTA ZSA1309A-R TRANSISTOR
0653 288621AQSTA 2SBGZ1ARTA TRANSISTOR A
0654, 655 ZSA1309AIRTA 25A1309A-R TRANSISTOR
