RS-DC10
I Mechanism
Heads:
Tape drive system:
Zachannel thin film head
Single capstan drive
(Auto reverse)
Tape drive motors
Capstan: DC servo motor
Reel table: DC motor
Tape speed: 4.76cm/sec. (1-7/8 ips.)
Fast forward and rewind times:
Approx. 100sec.
with 0-60 cassette tape
I CONTENTS
ACCESSORIES ...............
MAIN FEATURES OF DCC
THIN-FILM HEAD AND TRACK DISTRIBUTION..
CONNECTIONS .........................
CAUTION FOR AC MAINS LEAD
SEGGESTIONS FOR SAFET
LOCATION OF CONTROLS ..
ABOUT DCC TAPE..
SCMS
HANDLING PRECAUTIONS FOR DCC HEAD .
HEAD CLEANING METHOD
DISASSEMBLY INSTRUCTIONS..
HEAD ASSY REPLACEMENT .
OPERATIONAL CHECKING PR
MECHANISM BLOCK CHECK.....
HOW TO USE "SERVICE MODE"
ABOUT THE OPERATIONAL CHECKING POINTS.
BLOCK DIAGRAM...
I ACCESSORIES
I General
Power consumption: 35W
Power supply:
For (EG) area:
For (EB) area:
AC 50/60 HZ, 230V
AC 50/60 HZ, 240V
' For (G) area: . Ac 50I60Hz,
. 110V, 120V, 240V, 220V
Dimensions (WxHxD): 430x153x341 mm
Weight: 8.3kg
Note:
Specifications are subject to change without notice.
Weight and dimensions are approximate.
v Page
SCHEMATIC DIAGRAM ........................................................ a4~53
TERMINAL GUIDE OF ICS, TRANSISTORS
WIRING CONNECTION DIAGRAM .
PRINTED CIRCUIT BOARDS ........
PACKAGING
REPLACEMENT PARTS LIST .
RESISTORS AND CAPACITO ..
EXPLODED VIEWS (Cabinet parts loading parts
and Mechanical parts)
REPLACEMENT PARTS LIST
MEASUREMENT AND ADJUSTMENT
Note: 0 Refer to the measurement and adjustment of
supplement manual (Order No. A0921238908).
