Page 1
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
d a n g e r o u s v o l t a g e w i t h i n t h e p r o d u c t ' s
enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
p r e s e n c e o f i m p o r t a n t o p e r a t i n g a n d
maintenance (servicing) instructions in the
literature accompanying the appliance.
10) P r o t e c t t h e p o w e r c o r d f r o m b e i n g w a l k e d
on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
apparatus.
11) Only use attachments/accessories specified by the
manufacturer.
12) U s e o n l y w i t h t h e c a r t , s t a n d ,
tripod, bracket, or table specified
by the manufacturer, or sold with
t h e a p p a r a t u s . W h e n a c a r t i s
used, use caution when moving
the cart/apparatus combination
to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or
when unused for long periods of time.
14) Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
< Do not expose this apparatus to drips or splashes.
< Do not place any objects filled with liquids, such as
vases, on the apparatus.
< Do not install this apparatus in a confined space such
as a bookcase or similar unit.
< The apparatus draws nominal non-operating power
from the AC outlet with its POWER or STANDBY/ON
switch not in the ON position.
< The apparatus should be located close enough to the
AC outlet so that you can easily grasp the power cord
plug at any time.
< The mains plug is used as the disconnect device, the
disconnect device shall remain readily operable.
< If the product uses batteries (including a battery pack
or installed batteries), they should not be exposed to
sunshine, fire or excessive heat.
< Caution should be taken when using earphones or
headphones with the product because excessive
s o u n d p r e s s u r e ( v o l u m e ) f r o m e a r p h o n e s o r
headphones can cause hearing loss.
IMPORTANT SAFETY
INSTRUCTIONS
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in
accordance with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The
wide blade or the third prong are provided for your
safety. If the provided plug does not fit into your
outlet, consult an electrician for replacement of the
obsolete outlet.
2
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
Page 2
W A R N I N G : T O P R E V E N T F I R E O R
SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
CAUTION
< DO NOT REMOVE THE EXTERNAL CASES OR CABINETS
TO EXPOSE THE ELECTRONICS. NO USER SERVICEABLE
PARTS ARE WITHIN!
< I F Y O U A R E E X P E R I E N C I N G P R O B L E M S W I T H T H I S
PRODUCT, CONTACT TEAC FOR A SERVICE REFERRAL.
D O N O T U S E T H E P R O D U C T U N T I L I T H A S B E E N
REPAIRED.
< U S E O F C O N T R O L S O R A D J U S T M E N T S O R
PERFORMANCE OF PROCEDURES OTHER THAN THOSE
S P E C I F I E D H E R E I N M A Y R E S U L T I N H A Z A R D O U S
RADIATION EXPOSURE.
For U.S.A.
T h i s e q u i p m e n t h a s b e e n t e s t e d a n d f o u n d t o
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct
the interference by one or more of the following
measures:
< Reorient or relocate the equipment and/or the
receiving antenna.
< Increase the separation between the equipment
and receiver.
< C o n n e c t t h e e q u i p m e n t i n t o a n o u t l e t o n a
circuit different from that to which the receiver is
connected.
< Consult the dealer or an experienced radio/TV
technician for help.
CAUTION
C h a n g e s o r m o d i f i c a t i o n s t o t h i s e q u i p m e n t n o t
e x p r e s s l y a p p r o v e d b y T E A C C O R P O R A T I O N f o r
compliance will void the users warranty.
T h i s p r o d u c t h a s b e e n d e s i g n e d a n d m a n u f a c t u r e d
according to FDA regulations title 21, CFR, chapter 1,
subchapter J, based on the Radiation Control for Health
and Safety Act of 1968, and is classified as class 1 laser
product. There is not hazardous invisible laser radiation
during operation because invisible laser radiation emitted
inside of this product is completely confined in the
protective housings.
The label required in this regulation is shown as follows.
Optical pickup :
Type : SF-P101VF
Manufacturer : Sanyo Electric Co., Ltd
Laser output : Less than 1mW on the objective lens
Wavelength : 790±30nm
MPEG Layer-3 audio coding technology licensed from
Fraunhofer IIS and Thomson.
This product is protected by certain intellectual property
rights of Microsoft. Use or distribution of such technology
outside of this product is prohibited without a license
from Microsoft.
Made for iPod means that an electronic accessory
has been designed to connect specifically to iPod and
h a s b e e n c e r t i f i e d b y t h e d e v e l o p e r t o m e e t A p p l e
performance standards.
Apple is not responsible for the operation of this device
or its compliance with safety and regulatory standards.
Apple and iPod are trademarks of Apple Inc., registered in
the U.S. and other countries.
iPhone is a trademark of Apple Inc.
SDHC Logo is a trademark of SD-3C, LLC.
3
Page 10
ENGLISH
11
AM Indoor Loop Antenna
The high-performance AM loop antenna provided
with this unit is sufficient for good reception in most
areas.
To stand the loop antenna on a surface, fix the claw to
the slot in the antenna base.
Connect the loop antenna's wires to the AM antenna
terminals.
Place the antenna on a shelf or hang it on a window
frame, etc., in the direction which gives the best
reception. Keep all other wires such as power cords,
speaker wires or interconnect wires as far away as
possible from the antenna.
> If the AM loop antenna provided does not deliver
sufficient reception (often due to being too far from
the transmitter or in a concrete building, etc.), it may
be necessary to use an outdoor AM antenna.
Use either a high quality commercial AM antenna
or, if not available, an insulated wire more than 5 m
(16-2/5 ft.) long, strip one end, and connect this to the
terminal as shown.
T h e a n t e n n a w i r e s h o u l d b e s t r u n g o u t d o o r s o r
indoors near a window. For better reception, connect
the GND terminal to a reliable ground.
Note:
Even when using an outdoor AM antenna, do not
disconnect the indoor AM loop antenna.
Connecting Antennas (AM/FM)
Make sure to connect:
white wire q white terminal
black wire q black terminal (GND)
AM outdoor
antenna
FM Indoor Antenna
Connect the lead-type FM antenna to the FM 75 !
socket, extend the lead and tune the tuner to your
favorite station (see page 30). Adjust the antenna in
a suitable location like a window frame or wall until
the reception is best and then affix the antenna in
that position using thumb tacks, push pins or any
other suitable means.
FM Outdoor Antenna
In an area where FM signals are weak, it will be
necessary to use an outdoor FM antenna. Generally,
a 3-element antenna will be sufficient; if you live
in an area where the FM signals are particularly
weak, it may be necessary to use one with 5 or more
elements.
< Disconnect the FM indoor antenna when using an
outdoor antenna.
Page 102
RPT 1
RPT ALL
RPT Folder
ESPAÑOL
103
Pulse el botón REPEAT 1/ALL durante la reproducción.
El modo de repetición cambia como sigue:
< El modo de repetición se cancela cuando se detiene la
reproducción o se cambia la fuente:
Repetir una pista/archivo (RPT 1)
Se reproducirá repetidamente la pista que se está
escuchando. Si pulsa el botón de salto ( . o/ )
y s e l e c c i o n a o t r a p i s t a / a r c h i v o , l a p i s t a / a r c h i v o
seleccionado se repetirá repetidamente.
Repita todos los archivos de la carpeta (RPT Folder)
(sólo MP3/WMA)
T o d a s l a s p i s t a s d e l a c a r p e t a s e r e p r o d u c i r á n
repetidamente.
< Este modo se omite cuando no hay carpeta en el
disco.
Repite todas las pistas/archivos (RPT ALL)
T o d o s l a s p i s t a s / a r c h i v o s s e r e p r o d u c i r á n
repetidamente.
Durante la reproducción programada, todas las pistas/
archivos se reproducirán repetidamente.
Reproducción
normal
Reproducción repetida (disco/USB/SD)
(Sólo archivos MP3/WMA)
Reproducción aleatoria (disco/USB/SD)
Pulse el botón SHUFFLE durante la reproducción o en
el modo de parada.
Aparece Random en la pantalla y las pistas/archivos
se reproducen aleatoriamente.
< Si pulsa el botón / d u r a n t e l a r e p r o d u c c i ó n
aleatoria, la siguiente pista/archivo se seleccionará al
azar y se reproducirá. Si pulsa el botón . , la pista/
archivo actual se reproducirá desde el principio.
< Para cancelar la reproducción aleatoria, vuelva a pulsar
el botón SHUFFLE.
< Para detener la reproducción aleatoria, vuelva a pulsar
el botón STOP ( H).
