CD-450 Technical Documentation
7733 Telegraph R oad - Montebello , CA 90640 - (323) 726-0303 - http://www .tascam.comAll features and specifications are subject to change without notice. C\
ontact y our local TASCAM representativ e for the latest information. Page 2 of 2 CD-450_TECHDOC_031100.pdf
OPTIONAL REMOTE FADER START & EVENT START
PLAY
READY
RING RING FADER/EVENT START connector
TIP TIP
SLEEVE
SLEEVE
+5VGND50 ms or more
RING RING FADER/EVENTSTART connector
TIP TIP
SLEEVE
SLEEVE
FRONT & BACK PANELS
Shown with Optional LA-450. (LA-450 adds balanced XLR analog output an\
d AES/EBU digital output.
FADER ST ART is a latched function. Pla ybackbegins when the sleeve and tip of the TRS plugare connected, and will stop when the connectionis released.
ARCHITECT'S SPECIFICATIONS
EVENT START is a command function. Pla ybackwill begin when the ring and sleev e are connected for 50 milliseconds or longer .
The CD player shall be a single disc pla yer with a powered loading tr ay. Itshall be able to mount in a standard 19" r ack mount, occup ying two rackspaces in height. Dimensions shall be 19" x 4.1" x 11.9" (W x H x D).
Metric measurements: 482x104x304mm.
The CD pla yercueing functions including A uto Cue,Call, Incremental Play, and A utoReady .
Pitch controlappro ximately ±12%, and adjustable from the front panel. A pitch control in/out indicator shall be present on the front panel.
Analog outputs shall be unbalanced RCA connectors. Digital
outputs shall be pro vided on coaxialSPDIF connectors. Balanced analog XLR connectors and digital AES/EBU ports shall be provided on an optional balancing kit, specifically the LA -450.
The CD player shall be controllable an optional T ASCAM RC -450C wired remote, which shall offer access to all of the machine's major functions. A TRS connector on the back shall offer broadcast standard fader start and ev ent start control. An additional TRS shall offer tallies for play, stop , and EOM messages.
The CD playerCD-450.
NOTE: This textfile on TASCAM's
