Page 1
2 TASCAM 322
Important Safety Precautions
DO NOT cut off the mains plug from this equipment.
If the plug fitted is not suitable for the power points in your home or
the cable is too short to reach a power point, then obtain an
appropriate safety approved extension lead or consult your dealer.
If nonetheless the mains plug is cut off, remove the fuse and
dispose
of the plug
immediately, to avoid a possible shock hazard by
inadvertent connection to the mains supply.
If this product is not provided with a mains plug, or one has to be
fitted, then follow the instructions given below:
IMPORTANT: DO NOT make any connection to the larger
terminal which is marked with the letter E or by the safety earth
symbol \b or coloured GREEN or GREEN-and-YELLOW.
The wires in the mains lead on this product are coloured in
accordance with the following code: BLUE : NEUTRAL
BROWN : LIVE
As these colours may not correspond with the coloured markings
identifying the terminals in your plug proceed as follows:
The wire which is coloured BLUE must be connected to the terminal
which is marked with the letter N or coloured BLACK.
The wire which is coloured BROWN must be connected to the
terminal which is marked with the letter L or coloured RED.
When replacing the fuse only a correctly rated approved type should
be used and be sure to re-fit the fuse cover.
IF IN DOUBT - CONSULT A COMPETENT ELECTRICIAN.
IMPORTANT (for U.K. Customers)
TO THE USER
This equipment has been tested and found to
comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reason-
able protection against harmful interference
when the equipment is operated in a commer-
cial environment. This equipment generates,
uses, and can radiate radio frequency energy
and, if not installed and used in accordance with
the instruction manual, may cause harmful
interference to radio communications.
Operation of this equipment in a residental area
is likely to cause harmful interference in which
case the user will be required to correct the
interference at his own expense.
CAUTION
Changes or modifications to this equipment not
expressly approved by TEAC CORPORATION
for compliance could void the users authority to
operate this equipment.
For U.S.A
AC POWER CORD CONNECTION
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH
WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
CORDE DE CONNEXION CA
ATTENTION:
POUR ÉVITER LES CHOCS ÉLECTRIQUES,
INTRODUIRE LA LAME LA PLUS LARGE DE
LA FICHE DANS LA BORNE
CORRESPONDANTE DE LA PRISE ET
POUSSER JUSQUAU FOND.
For CANADA
Page 2
TASCAM 322 3
CAUTION:
-¦Read all of these Instructions.
-¦ Save these Instructions for later use.
-¦ Follow all Warnings and Instructions marked on the audio
equipment.
1) Read Instructions - All the safety and operating instructions should
be read before the product is operated.
2) Retain Instructions - The safety and operating instructions should
be retained for future reference.
3) Heed Warnings - All warnings on the product and in the operating
instructions should be adhered to.
4) Follow Instructions - All operating and use instructions should be
followed.
5) Cleaning - Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cle\
an-
ing.
6) Attachments - Do not use attachments not recommended by the
product manufacturer as they may cause hazards.
7) Water and Moisture - Do not use this product near water - for
example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a \
wet
basement; or near a swimming pool; and the like.
8) Accessories - Do not place this product on an unstable cart, stand,
tripod, bracket, or table. The product may fall, causing serious injury \
to a
child or adult, and serious damage to the product. Use only with a cart,\
stand, tripod, bracket, or table recommended by the manufacturer, or sol\
d
with the product. Any mounting of the product should follow the manufac-\
turers instructions, and should use a mounting accessory recommended\
by
the manufacturer.
9) A product and cart combination should be moved with care. Quick stops,
excessive force, and uneven surfaces may cause the product and cart com-\
bination to overturn.
10) Ventilation - Slots and openings in the cabinet are provided for ven-
tilation and to ensure reliable operation of the product and to protect\
it
from overheating, and these openings must not be blocked or covered. The\
openings should never be blocked by placing the product on a bed, sofa,
rug, or other similar surface. This product should not be placed in a bu\
ilt-in
installation such as a bookcase or rack unless proper ventilation is pro\
vided
or the manufacturers instructions have been adhered to.
11) Power Sources - This product should be operated only from the
type of power source indicated on the marking label. If you are not sure\
of
the type of power supply to your home, consult your product dealer or lo\
cal
power company. For products intended to operate from battery power, or
other sources, refer to the operating instructions.
12) Grounding or Polarization - This product may be equipped with
a polarized alternating-current line plug (a plug having one blade wide\
r
than the other). This plug will fit into the power outlet only one way.\
This is
a safety feature. If you are unable to insert the plug fully into the ou\
tlet, try
reversing the plug. If the plug should still fail to fit, contact your e\
lectrician
to replace your obsolete outlet. Do not defeat the safety purpose of the\
polarized plug.
13) Power-Cord Protection - Power-supply cords should be routed so
that they are not likely to be walked on or pinched by items placed upon\
or
against them, paying particular attention to cords at plugs, convenience\
receptacles, and the point where they exit from the product.
14) Outdoor Antenna Grounding - If an outside antenna or cable
system is connected to the product, be sure the antenna or cable system\
is
grounded so as to provide some protection against voltage surges and bui\
lt-
up static charges. Article 810 of the National Electrical Code, ANSI/NFP\
A
70, provides information with regard to proper grounding of the mast and\
supporting structure, grounding of the lead-in wire to an antenna discha\
rge
unit, size of grounding conductors, location of antenna-discharge unit, \
con-
nection to grounding electrodes, and requirements for the grounding elec\
-
trode. "Note to CATV system installer:
This reminder is provided to call the CATV system installers attenti\
on to
Section 820-40 of the NEC which provides guidelines for proper grounding\
and, in particular, specifies that the cable ground shall be connected t\
o the
grounding system of the building, as close to the point of cable entry a\
s
practical.
15) Lightning
- For added protection for this product during a lightning
storm, or when it is left unattended and unused for long periods of time\
,
unplug it from the wall outlet and disconnect the antenna or cable syste\
m.
This will prevent damage to the product due to lightning and power-line
surges.
16) Power Lines - An outside antenna system should not be located in
the vicinity of overhead power lines or other electric light or power ci\
rcuits,
or where it can fall into such power lines or circuits. When installing \
an
outside antenna system, extreme care should be taken to keep from touch-\
ing such power lines or circuits as contact with them might be fatal.
17) Overloading - Do not overload wall outlets, extension cords, or
integral convenience receptacles as this can result in risk of fire or e\
lectric
shock.
18) Object and Liquid Entry - Never push objects of any kind into
this product through openings as they may touch dangerous voltage points\
or short-out parts that could result in a fire or electric shock. Never \
spill
liquid of any kind on the product.
19) Servicing - Do not attempt to service this product yourself as open-
ing or removing covers may expose you to dangerous voltage or other
hazards. Refer all servicing to qualified service personnel.
20) Damage Requiring Service - Unplug this product from the wall
outlet and refer servicing to qualified service personnel under the foll\
owing
conditions:
a) when the power-supply cord or plug is damaged.
b) if liquid has been spilled, or objects have fallen into the product.
c) if the product has been exposed to rain or water.
d) if the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operati\
ng
instructions as an improper adjustment of other controls may result in
damage and will often require extensive work by a qualified technician t\
o
restore the product to its normal operation.
e) if the product has been dropped or damaged in any way.
f ) when the product exhibits a distinct change in performance -“ this
indicates a need for service.
21) Replacement Parts - When replacement parts are required, be
sure the service technician has used replacement parts specified by the
manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock, or other
hazards.
22) Safety Check - Upon completion of any service or repairs to this
product, ask the service technician to perform safety checks to determin\
e
that the product is in proper operating condition.
23) Wall or Ceiling Mounting - The product should be mounted to a
wall or ceiling only as recommended by the manufacturer.
24) Heat - The product should be situated away from heat sources such
as radiators, heat registers, stoves, or other products (including ampl\
ifiers)
that produce heat.
ANTENNA
LEAD IN
WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250. PART H)
NEC - NATIONAL ELECTRICAL CODE ELECTRIC
SERVICE
EQUIPMENT
Example of Antenna Grounding as per
National Electrical Code, ANSI/NFPA 70
GROUND
CLAMP
IMPORTANT SAFETY INSTRUCTIONS
