Extracted text from Tascam 2011 Catalog (Ocr-read)
Page 1
- Dual Compact Flash recording media supports backup,
mirroring and seamless A/B recording
- Long battery life through low power usage
- Easy to read and operate using pivoting TFT Color Touch
Panel interface
- All-aluminum chassis is rugged yet lightweight
- 8-track recording plus stereo mix for a total of 10-track
recording
- 8-track recording at up to 96kHz/24-bit
- 4-track recording at 192kHz/24-bit
- Broadcast WAV (BWF) support with iXML metadata
- Various power options include AA batteries (x10), NP
type, AC adaptor, external DC input and optional V-
mount adaptor for ENDURA batteries
- Up to 5-second pre-record buffer
- Internal microphone for slate recording
- Limiter and low-cut filter per track
- Auto or manual cue points
- Alert signal to headphone output
- Retake function
- Panel lockout function to prevent accidental transport
switching
- 8 high-quality microphone preamps and A/D convert-
ers with independent +48V phantom power for each
(standard XLR connectors)
- 8 AES/EBU inputs and outputs (DB-25 connector)
- Sampling rate converter on each AES/EBU input
- 2 balanced analog outputs (XLR connector)
- Stereo digital output (BNC connector)
- SMPTE Timecode In and Out (BNC connector)
- Video/Word Clock/Cascade I/O (BNC connector)
- Headphone out (1/4 stereo jack)
- PS/2 keyboard input for track naming
- USB 2.0 high-speed data transfer to PC
- Optional AR-P82 case by PortaBrace
- 8 lbs (without battery) TASCAMs HS-P82 offers 8 tracks of the highest quality recording, yet
its built for the rigors of location recording with reliable solid-state per -
formance. The HS-P82 is built for location television and film production
audio, with eight microphone inputs for big shoots or reality programs.
The standard XLR microphone inputs include phantom power and analog
limiting, with trims controlled from recessed front-panel controls. In addition
to the eight individual tracks, a stereo mixdown can be recorded for instant
use during editing.
Audio is recorded at up to 192kHz/24-bit WAV format to a pair of Com-
pact Flash cards. This solid state media is completely reliable with no
moving parts, and you can record to both cards simultaneously for extra
security. The Broadcast WAV files include iXML metadata for quick import
into nearly any video or audio editing system via the USB 2.0 connection
or a standard card reader.
The HS-P82 offers several options for power. It runs on either AA or NP
batteries, an included AC adapter, external DC input or a V-mount adapter
for Endura batteries. An internal slate microphone is available for naming
takes. A 5-second pre-record buffer, front panel lockout and headphone
output alert signal inspire confidence in recorded takes.
For high-resolution music recording, a set of AES/EBU connectors is avail-
able for attaching pedigree A/D converters and preamplifiers. SMPTE time-
code in and out, video and word sync are provided. All of this is controlled
from a color touchscreen interface which makes operation fast and simple.
The HS-P82 from TASCAM is built on 30 years of reliable field recording.
See how affordable the state of the art can be with TASCAMs flagship
production recorder, the HS-P82.
RC-F82
Fader Controller for HS-P82
Page 2
- 8-channel/2-channel solid-state recorder
- Records to Compact Flash media, dual
slots for mirroring or continuous recording
- 8-channel 96kHz/24-bit Broadcast WAV
file recording (HS-8)
- 4-channel recording at 192kHz/24-bit
resolution (HS-8)
- 8-channel recording plus stereo mix track
at 44.1/48k resolution (HS-8)
- Internal stereo mixer (level/pan, HS-8)
- BWF file format with iXML metadata
- Multi-channel flash start (HS-8)
- Color TFT touch panel interface
- 5-second pre-record buffer
- Cascade function for multiple unit operation
- (8) balanced analog inputs/outputs on
25-pin D-sub connectors (HS-8) -
Balanced stereo analog inputs/outputs on
XLR connector (HS-2)
- XLR stereo analog input and output
(Assignable, HS-8)
- AES/EBU digital I/O (HS-8: 8-channel
25-pin D-sub; HS-2: Stereo XLR)
- XLR stereo AES/EBU I/O (Assignable,
HS-8)
- 8-channel ADAT optical digital in and out
(HS-8)
- Video and word clock on BNC
- SMPTE timecode BNC in/out (HS-8,
optional on HS-2)
- PS/2 keyboard input
- RS-232C serial control input
- RS-422 serial control input (HS-8,
optional on HS-2)
TASCAMs HS-8 and HS-2 are the first solutions for professional multi-
track recording and playback to solid-state media. From studio surround
recording to post production playback of HS-P82 location recordings, the
HS-8 fits a variety of multitrack roles first pioneered by TASCAMs DA-88
recorders. True to TASCAM tradition, audio is top-quality throughout with
up to 192kHz/24-bit recording.
Like the HS-P82, the HS-8 uses a color touch-screen interface to access set-
tings and tracks. A stereo mixer is built in for monitoring, and the mix can
be recorded live as a separate track. Audio is recorded as Broadcast WAV
files to Compact Flash media, with SMPTE timecode available on various
interfaces. A pair of CF card slots is available for data mirroring or continu-
ous recording.
The HS-2 adds affordable stereo recording and playback to solid state
media. Timecode on the HS-2 is added through an option card, the SY-2,
making it an ideal broadcast replacement for timecode DAT recorders. The
RC-HS20PD remote control allows operation of either recorder from a
separate room over a RJ-45 connection.
TASCAMs HS-8 and HS-2 provide the sound quality, instant access and
ease-of-use that studio and post professionals demand.
RC-HS20PD
Direct Play Remote
with Touchscreen & Fader Start RC-SS20
Direct Play Remote
Pictured with optional SY-2 synchronization card installed
