Physical Dimensions and Weight
Height: Back: 5 (127 mm)
Front: 2.5 (64 mm)
Width: 18.45 (469 mm)
Depth: 16.6 (422 mm)
Weight: 11.5 lbs (5.2 kg)
Internal Effects
32 bit EMAC processing, 2-channel
Sample Rate: 31.25kHz
Bandwidth: 15.6kHz
Number of presets: 16
Parameters: 2 controls
Digital I/O
USB
Bit Depth: 24 bit/16 bit
Sample Rates: 44.1 kHz, 48 kHz,
Output: Main L and R output signal or
Subgroup 1-2
Input: Alternate source to stereo
channel 15-16
Disclaimer
Since we are always striving to make our products
better by incorporating new and improved materials,
components, and manufacturing methods, we
reserve the right to change these specifications at
any time without notice.
System Requirements
Here are some of the computer requirements in
order to use the mixer with a computer and to run the
Tracktion software.
PC Requirements
- WINDOWS XP
- Intel Pentium 3 or 4, or AMD Athlon (750 MHz or
better is recommended for Tracktion).
- At least 128 MB RAM; 256 MB is recommended for
heavy-duty Tracktion work.
- Super VGA (1024 x 768) or higher-resolution video
adapter and monitor.
- CD-ROM or DVD drive.
- Keyboard and Wheel Mouse or compatible
pointing device.
- USB port
Macintosh Requirements
- Macintosh OS 10.3
- Power Mac G3, or G4, iMac, eMac, Powerbook G3
or G4, or iBook computer with 128 MB of physical
RAM. (The original early PowerBook G3 upgrade
cards are not supported by OS X).
Hard Drive Notes
- To record a one minute 24-bit/44.1 kHz mono track
requires approximately 8 MB of hard drive space.
- Preferably, use a second drive for recording audio,
not your main drive with the operating system.
- It is best if you can start with a freshly de-
fragmented drive before recording.
- Backup your files and de-fragment your drive
often.
- Did we mention backing up your files often?
- We do not want you to be sitting back relaxing in
the pub after a long day's recording session of your
finest work, when all along there is a doubt in the
back of your mind about having backed up your
files.
