Tandberg 1200 X Service Manual

Page 1

March 1970 R4 fie

PRDID?

Service manual

TAN DBERG

Tape recorder
model 1200X

Page 2

PREFACE

This manual covers the 2-track and 4-track versions
of Tandberg Stereo TapeRecorder Series 1200K. The
two versions have the same tape transport.All circuits
are transistorized. Cross-field biasing technique is
utilized. Separate amplifier-star microphone- and line
inputs, equalizing amplifiers and output amplifiersare
provided for each channel. Units above serial number
2 252 600 are adjusted for Low Noise tape. Pick- up
selector was introduced from serial number 2 237 000.
The various modifications of Series 1200)( since pro-
duction started are listed in chapter 6.0.

The description of all electric circuits except the po-
wer supply is referred to circuit diagram valid from
serial no. 2 237 000.

when ordering spare parts, observe that only those
parts appearing in the spare parts list are available.
We hope that this manual will be of help to everyone

concerned with servicing of Series 1200K.

Oslo, March 1970

TANDBERGS RADIOFABRIKK A/S
