Page 1
Revision Histor y:
17 November 2005 internal release
17 July 2006 first public release
Notes:
Version Check:
To check the version on the unit, please follow the procedure below.
1. Turn on the unit.
2. Press DISPLAY + STANDBY/ON buttons.
3. Two versions will be displayed sequentially. Check the first version "MSxxxxx".
The version number shows the date (ymdd) in which the firmware was created. Here, X, Y
and Z in month mean Oct
, Nov and Dec res pectivel y.
Version Date Contents
Date Contents Model1.0
1.1
Support: 425.335.4748 Copyright © 2006 Sunfire Corporation 2 / 12
Page 2
SUNFIRERS-232 Protocol, v1.1
1 Hardware Overview
3wire RS-232C protocol
19200 or 9600 baud / 8 data bits / 1 stop bits / no parity / no flow control (baud is selectable via OSD
)
9 pin female D type connector (pin 2 is transmit, pin 3 is receive, pin 5 is signal ground)
Use a straight-thru cable to connect to your control system or PC.
9600 baud
8 data bits
No parity
No flow control
2 Protocol Overview
1st 2nd-4th 6th-Nth last
End Character*
[CR] = "0x0D" hex or "13" decimal
Command Parameter
(of variable length)
Start Character
* Some control s
ystems use a s pecial character (such as "
" or "
" ) to re present a carria ge
return, [CR]. Please check with your control system provider if you are not sure what
character or string they use. Sunfire's RS-232 protocol is a very sophisticated, yet simple to use interface to 3rd party control
systems such as Elan, Crestron, AMX, and others. Each command is structured as outlined
below:
The start character ("*") tells the Sunfire unit that a command is about to follow. The command +
parameter instruct the unit to perform a certain operation. The unit will then execute that action
upon receiving the [CR] string.ON P W R [CR] *
GND
RX
TX
DB9 Male to plug
into Sunfire
Support: 425.335.4748 Copyright © 2006 Sunfire Corporation 3 / 12
