User's Manual
WARNING: THIS SUBWOOFER SYSTEM IS CAPABLE OF PRODUCING VERY HIGH SOUND PRESSURE LEVELS. YOU MUST TAKE EVERY PRECAUTION TO PROTECT YOUR HEARING FROM PERMANENT DAMAGE.
Important Safety Instructions
1. Read Instructions
2. Keep these Instructions
3. Heed all Warnings.
4. Follow all Instructions
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
8. Unplug this apparatus during lightning storms or when unused for long periods of time.
9. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as a power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
10. Installation should only be performed by qualified and experienced professional installers. Refer to your Sunfire dealer.
The SubRosa subwoofer is a finely tuned system and should only be used with the Sunfire SRA-2700EQ companion amplifier. Using any other amplifier will offer inferior performance and may void your warranty.
Safety
2
Page 2
User's Manual
For more information on this and other Sunfire
products, please visit our website:
www.sunfire.com
Safety Instructions ............ 2
Introduction ...................... 4
Unpacking ........................ 5
Dimensions ...................... 6
Location ............................ 7
Framing ............................ 9
Cabinet installation ........... 10
Wiring ............................... 11
Final rough-in ................... 12
Horizontal mounting ......... 14
Baffle installation .............. 16
Grille installation ............... 18
Contents
Cabinet
Baffle Install
Grille Install
