Page 1
User's Manual
Important Safety
Instructions
1. Read Instructions
2. Keep these Instructions
3. Heed all Warnings.
4. Follow all Instructions
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
8. Unplug this apparatus during lightning storms or when unused for long periods of time.
9. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as a power-supply cord or plug is dam - aged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
10. Ventilation - The apparatus should be situated so that its location or position does not interfere with its proper ventilation. For example, the apparatus should not be situ - ated on a bed, sofa, rug, or similar surface that may block any ventilation openings; or placed in a built-in installation such as a bookcase, cabinet, or closed equipment rack that may impede the flow of air through ventilation openings.
11. Power Sources - The apparatus should be connected to a power supply only of the type described in these operation instructions or as marked on the apparatus.
12. Power Cord Protection - Power-supply cords should be routed so that they are not likely to be walked upon or pinched by items placed upon or against them, paying particu - lar attention to cords at plugs, convenience
receptacles, and the point where they exit the apparatus.
13. Non-use Periods-The power cord of the apparatus should be unplugged from the outlet when unused for a long period of time.
14. Object and Liquid Entry - Care should be taken so that objects do not fall into and liquids are not spilled into the inside of the apparatus.
15. Servicing - The user should not attempt
to service the apparatus beyond those
means described in this operating manual. All other servicing should be referred to qualified service personnel.
16. To Prevent Electric Shock, do not use this polarized plug with an extension cord, receptacle or other outlet unless the blades can be fully inserted to prevent
blade exposure.
Pour préevenir les chocs électriques ne pas utiliser cette fiche polariseé avec un prolongateur, un prise de courant ou une autre sortie de courant, sauf si les lames peuvent être insérées à fond sans laisser aucune pariie à découvert.
17. Grounding or Polarization - Precau - tions should be taken so that the ground - ing or polarization means of the Com - ponent is not defeated.
This apparatus does not exceed the Class A/Class B (whichever is applicable) limits for radio noise emissions from digital ap - paratus as set out in the radio interference regulations of the Canadian Department of Communications.
ATTENTION - Le présent appareil numéri - que n'émet pas de bruits radioélectriques dépassant las limites applicables aux ap - pareils numériques de class A/de class B (selon le cas) prescrites dans le règlement sur le brouillage radioélectrique édicté par les ministere des communications du Canada.
Page 2
User's Manual
Safety Instructions .........................................
Introduction ...................................................
4
Features ........................................................
4
Unpacking and Care .....................................
4
Overview ....................................................... 5
Amplifier Features .........................................
6
Amplifier Installation ......................................
9
Connections ................................................
10
Subwoofer Installation ................................. 11
Room Equalization Procedure .................... 1
System Configurations ................................ 14
Adjusting the Controls .................................
17
Specifications ..............................................
18
Subwoofer Installation Instructions ............. 19
Troubleshooting Guide ................................ 1
Limited Warranty ......................................... 3
Service Assistance ...................................... 3
For more information on this and other Sunfire products,
please visit our website: www.sunfire.com
WARNING: THIS SUBWOOFER IS CAPABLE OF PRODUCING VERY HIGH SOUND PRESSURE LEVELS. YOU MUST TAKE EVERY PRECAUTION TO PROTECT YOUR HEARING FROM PERMANENT DAMAGE.
Contents
3
