Studer 970 Service Manual 3

Extracted text from Studer 970 Service Manual 3 (Ocr-read)

Page 1

Professional Audio System ComponentsE14Date printed: 29.11.01Technical SpecificationsInput: Impedance³ 10 kW, electronically balanced Clipping point+24 dBu Output:Electronically balanced Recommended load³ 2 kW Maximum level+24 dBu Frequency response-“0.5 dB, 30 Hz...15 kHz Gain/attenuation range+40...-“100 dB, with ext. control Control input: pin1; gain tracking0 V = unity gain; 1 dB/µA; jumper 1-2 20 dB/V; jumper 2-3 10 dB/V; jumper 3-4 Control input: pin10; gain tracking10 dB/V THD< 0.1% Equivalent input noise-“93 dBu @ unity gain Supply:±15 V (25 mA) Dimensions:MS-card, 34 × 85 mm Ordering Information:VCA with electronically balanced input and output1.914.515.xx
