XEP-350II
SERVICE MANUAL
US Model
Canadian Model
AEP Model
E Model
SPECIFICATIONS
Crossover irequency
3.500 Hz
Filter slope -12 dB/ocl
Dimensions Approx. 74 x 30 x 120 mm (wlhld)
(3 x 13/3 x 43/. inches)
Weight Approx. 220 g (8 oz)
Accessories supplied
Mounting hardware (1 set)
Design and specifications subject to change without notice.
PARTS LIST
& Part No. Descriglion
1 1239-07911 ENCAPSULATED COMPONENT
2 1-537~361»21 TERMINAL BOARD (6P)
3 3367-916-11 CASE, UPPER
4 *3367-917-01 CASE, LOWER
ACCESSORY & RACKING MATERIAL
l1fit>k$¥ttli1ttttiltttit
X-3362v928v1 ASSY. SCREW
3753-13321 MA/NUAL. INSTRUCTION (ENGLISH/FRENCH)
(U C)
3753-13341 MANUAL INSTRUCTION
(ENGLISH/F/D/E/NL/S/I/P/RC) (AEP/E)
3-367»141~OI CUSHION
*3v367144-01 INDIVIDUAL CARTON
0 Items marked "" are not stocked since they
are seldom required for routine service Some
delay should be anticipated when ordering these
items
EXPLODED VIEW
snussnvm NETWIJRK
S ON Y;
XEP-3500
CONNECTIONS DIAGRAM
Power ampliler
Right Lelt
Black striped
9' XS-HS/HS
0
Right
0
Gray
Black striped
Crossover network Black striped
m r :59
fi
Lelt
While
Blane
Black striped XS'MMWLE
9
Flight
9
0
Gray
Notes on tweeter connection.
' When you use the XS-H5/H6 as a tweeter in combination with the
XSAM4/L51L6 as shown above. we recommend you to connect the
tweeters with reverse polarity tor obtaining a better sound. Connect
the 6) (black striped) leads 0! the XS-HSIHG to the 6 terminals 0!
the XEP-SSOO.
- When you use tweeters other than those shown above, check the
suitable polarity oi the tweeters belore connecting them.
English
- 91A0476-1
Sony Corporation Primed in Japan
' © 1991. 1
Mobile Electronics Group
Zi
9-956-232-1 1
Published by Customer Relations and Service Group
