Notes on chip component replacement
¥ Never reuse a disconnected chip component.
¥ Notice that the minus side of a tantalum capacitor may be
damaged by heat.
Flexible Circuit Board Repairing
¥ Keep the temperature of soldering iron around 270ûC
during repairing.
¥ Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
¥ Be careful not to apply force on the conductor when soldering
or unsoldering.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK ! OR DOTTED LINE WITH
MARK ! ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS
LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE
COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS
APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS
PUBLISHED BY SONY.
TABLE OF CONTENTS
1. SERVICE NOTE
ááááááááááááááááááááááááááááááááááááááááááááááááááá\
áááááááááááá 3
2. GENERAL ááááááááááááááááááááááááááááááááááááááááááááááááááá\
ááááááááááááááááááááááá 5
3. DISASSEMBLY
3-1. Case Block Assembly ááááááááááááááááááááááááááááááááááááááááááááááááááá\
áá 6
3-2. Belt (F2) ááááááááááááááááááááááááááááááááááááááááááááááááááá\
ááááááááááááááááááááááá 7
3-3. Cassette Lid Assembly ááááááááááááááááááááááááááááááááááááááááááááááááááá\
á 7
3-4. Reel Ornament Assembly ááááááááááááááááááááááááááááááááááááááááááááááá 8
3-5. Main Board ááááááááááááááááááááááááááááááááááááááááááááááááááá\
áááááááááááááááááá 8
3-6. Motor (F2) (M901) ááááááááááááááááááááááááááááááááááááááááááááááááááá\
áááááá 9
3-7. Holder Assembly ááááááááááááááááááááááááááááááááááááááááááááááááááá\
áááááááááá 9
3-8. Pinch Lever (N)/(R) Assembly ááááááááááááááááááááááááááááááááááááá 10
3-9. Magnetic Head (HP901) ááááááááááááááááááááááááááááááááááááááááááááááá 10
4. MECHANICAL ADJUSTMENT áááááááááááááááááááááááááááááááá 11
5. ELECTRICAL ADJUSTMENT áááááááááááááááááááááááááááááááááá 11
6. DIAGRAMS
6-1. Block Diagram ááááááááááááááááááááááááááááááááááááááááááááááááááá\
ááááááááááá 13
6-2. Printed Wiring Board ááááááááááááááááááááááááááááááááááááááááááááááááááá\
á 16
6-3. Schematic Diagram (1/2) áááááááááááááááááááááááááááááááááááááááááááááá 19
6-4. Schematic Diagram (2/2) áááááááááááááááááááááááááááááááááááááááááááááá 22
6-5. IC Block Diagrams ááááááááááááááááááááááááááááááááááááááááááááááááááá\
áááá 25
6-6. IC Pin Function Discription áááááááááááááááááááááááááááááááááááááááááá 27
7. EXPLODED VIEWS
7-1. Cabinet Block, Main Board áááááááááááááááááááááááááááááááááááááááááá 29
7-2. Mechanism Deck Block áááááááááááááááááááááááááááááááááááááááááááááááá 30
8. ELECTRICAL PARTS LIST ááááááááááááááááááááááááááááááááááááááá 31
Page 2
Ñ 3 Ñ
p
(S3)
ENTER
(S10)BAND
(S8)MENU
(S6) R43
(SIDE A)Q15
(SIDE A)
PH1
(SIDE A)
SET
(S7)
(S1)
FWD
¬STOP ®REV Battery terminal
Õ
Battery terminal -
Square-wave
(sine wave)
10 Hz, -3.5 dB
AF OSC
Plunger (PM901)
Short
R TUME
SWITCH
(S901-2) TAPE DETECT
SWITCH
(S901-1)
FF AMS
(S4)
REW AMS
(S5)
Ï REPEAT
(S9)
M601
M
SECTION 1
SERVISE NOTE
[Service Mode]
The service mode enables to operate the mechanism of WM-FX671
while the MAIN board is opened.
Rotation of the idler gear (A) (S side) is detected using the photo-
reflector (PH1) in the WM-FX671. PH1 is located on the MAIN
board, therefore the rotation of the idler gear (A) (S side) cannot be
detected by PH1 when the MAIN board is removed. As a result, the
motor cannot be controlled and cannot run correctly.
To repair the machine after the MAIN board is removed while the
main power is turned on, follow the procedures as described below.
1. Setting
1) Remove the cabinets referring to section Ò3. DISASSEMBLYÓ.
Open the MAIN board.
2) Connect the motor (M601) and the plunger solenoid (PM901)
to the MAIN board using the jumper wires. When the extension
jig (1-769-143-11) (10 wires as a set) is used, they can be
connected easily.
3) Short the TAPE DETECT switch (S901-2), R TUME switch
(S901-1).
4) Connect an AF oscillator to resistor (R43).
5) Connect DC 1.3 V from external regulated power supply to -
and Õ terminals of the battery.
2. PRE-SET status
The PLAY, FF and REW modes can be entered only from the PRE-
SET status.
1) Check that the slider (NR) is in the center position (S1), and
the FWD/REV switch is also in the center position. When
these switches are not in the center position, set them to the
PRE-SET status as follows.
2) Move the FWD/REV switch (S1) to the same position as the
slider (NR) is set.
3) The slider (NR) can be moved when the main power of the
regulated power supply is turned OFF once then back ON.
Move the FWD/REV switch (S1) to the center position in
synchronism with the timing when the slider (NR) is moved.3. FF, REW modes
1) Check that the PRE-SET status is set.
2) Connect square wave or sine wave to resistor (R43). (See
illustration below.)
3) Press the p switch (S3) to enter the STOP mode.
4) Press the FF AMS switch (S4) and the REW AMS switch
(S5).
4. PLAY mode
1) Check that the PRE-SET status is set.
2) Connect square wave or sine wave to resistor (R43). (See
illustration below.)
3) Press the p switch (S3) to enter the stop mode.
4) When the 9(REPEAT switch (S9) of the MAIN board is
pressed, the slider (N/R) moves once to the F side then moves
to the R side. When the FWD/REV switch (S1) is pressed in
the synchronism with the above timing, the machine can enter
the PLAY (R side) mode. Press the 9(REPEAT switch
(S9) again, and move the FWD/REV switch (S1) in the
synchronism with the motion of slider (NR). It enables the
machine to enter into the PLAY (F side) mode.
Note 1: When you fail to enter the PLAY mode, re-start from step
1) PRE-SET status.
Note 2: Regarding the 9(REPEAT (S9), p (S3),
FF AMS (S4), and REW AMS (S5) switches, use these
switches of the remote control unit as much as possible.
Note 3: If a headphones are used, the beep sound shows the timing
of the FWD/REV switch (S1).
