SECTION 2
DISASSEMBLY
Note : Follow the disassembly procedure in the numerical order given.
2-1. CABINET (REAR) SUB ASSY
2-2. MAIN BOARD
z The equipment can be removed using the following procedure.
Main board Cabinet (rear) sub ASSY
Holder sub ASSY, CassetteMechanism deck Belt, Capstan/reel moter (M901)
Set
1 Screws B1.7x9
3 Claws
4
2
6
ClawsHolder sub ASSY, Cassette
Cabinet (front)
Cabinet (rear) sub ASSY
3 Claws 3 Claws
5 Claw
4 Claws
4 Claw
5 Claw
5 Claw
1 Screw WH1.4
3 Claws
2 Remove solder
4
Head flexible board
RedWhiteOrange
Black
Cabinet (front)
Main board
