Extracted text from sony tmr if 330 r service manual (Ocr-read)
Page 1
Page 2
Ð 5 ÐÐ 6 Ð
2-2. SCHEMATIC DIAGRAM
r IC BLOCK DIAGRAM
IC11 TA2061AF-EL
1 2 3 4 5 6 7 8
16 15 14 13 12 11 10 9
R-CH
IN
NF VREFL-CH
IN
AGC T/C AGC
ON/OFF
F0 ADJ (R) VCC
L-CH
OUT ADJ
ON/OFF AUTO
OFF T/C
GND
F0 ADJ (L)
SURROUND
ON/OFF
R-CH
OUT
LEVEL
DET.
LEVEL
DET.
AGC
MIX AMPAGC
O.S.M.Lout = L + K - (L-R)
Rout = R - K - (L-R)
PRE
EMPHASIS
PRE
EMPHASIS VCO
VCO BUFFER
BUFFER
VREF
TMR-IF330R
Note:
¥ All capacitors are in mF unless otherwise noted. pF: mmF
50 WV or less are not indicated except for electrolytics
and tantalums.
¥ All resistors are in W and
1/4
W or less unless otherwise
specified.
¥ % : indicates tolerance.
¥U: B+ Line.
¥H: adjustment for repair.
¥ Power voltage is dc 9 V and fed with regulated dc power
supply from external power voltage jack (J4).
¥ Voltages are dc with respect to ground under no-signal
conditions.
¥ Voltages are taken with a VOM (Input impedance 10 MW).
Voltage variations may be noted due to normal produc-
tion tolerances.
¥ Signal path.
F: AUDIO
J: RF
