-900DV

SERVICE MANUAL

Ver 1.0 2001.02

US Model
Canadian Model
AEP Model
Tourist Model

Model Name Using Similar Mechanism NEW

Tape Transport Mechanism Type MT-900-175

SPECIFICATIONS

Recording system
2-track 1 channel monaural
Tape speed
4.8 cm/s or 2.4 cm/s
Frequency range
150 - 6 300 Hz using nomal (TYPEI) cassette
(with REC TIME switc hat NORMAL")
Speaker
Approx. 3.6 cm (1 7/16 in.) dia.
Power output
250 mW (at 10 % harmonicdistortion)

Input
Microphone input jack (minijack)
sensitivity 0.12 mV for 3 kiloth or lower impedance
microphone

Output

Earphone jack (minijack) for 8 ~3OO ohms earphone
Variable range of the tape speed

From approx. +100% to -50% (with

REC TIME switch at NORMAL)

From approx. +100% to -30% (with

REC TIME switch at DOUBLE)

9-873-082-11 Sony Corporation
2001B0200-1 Audio Entertainment Group
©2001.2 General Engineering Dept.

Variable range of pitch control variation
Approx. +1 octave to -1 octave
Power requirements
3 V DC batteries R6 (AA) x 2
External DC 3 V power sources
Dimensions (w/h/d) (incl. projecting
parts and controls)
Approx. 867 x 112.8 x 35.7 mm
(3 1/2 X41/2 X 1 7/16 in.)
Mass
Approx. 200g (7.1 oz.)
Supplied accessories
Headphones with remote control (1)
R6 (size AA) batteries (2)
(Sony World Model" only)
Carrying pouch (1)

Design and specifications are subject
to change without notice.
