Extracted text from sony tcm 453 vk service manual (Ocr-read)
Page 1
Ð 2 Ð
TABLE OF CONTENTS
1. SERVICING NOTES
............................................... 2
2. GENERAL
Preparing a Power Source ............................................... 3
Recording ........................................................................ 3
Playing a Tape ................................................................. 3
Maintenance .................................................................... 3
3. DISASSEMBLY ......................................................... 4
4. MECHANICAL ADJUSTMENTS ....................... 7
5. ELECTRICAL ADJUSTMENTS ......................... 8
6. DIAGRAMS
6-1. Block Diagram ................................................................ 9
6-2. Printed Wiring Board ...................................................... 11
6-3. Schematic Diagram ......................................................... 13
7. EXPLODED VIEWS ................................................ 16
8. ELECTRICAL PARTS LIST ............................... 19In this set, the S102 (power) detects REC/PLAYBACK on.
It is mounted on the MAIN board, and therefore the REC/PLAY-
BACK on cannot be detected with the MAIN board removed.
When making an operation check and voltage check of mechani-
cal deck with the MAIN board removed, fix the S102 at turn on.
[MAIN BOARD] (Conductor Side)
ATTENTION AU COMPOSANT AYANT RAPPORT
Ë LA SƒCURITƒ!
LES COMPOSANTS IDENTIFIƒS PAR UNE MARQUE !
SUR LES DIAGRAMMES SCHƒMATIQUES ET LA LISTE
DES PIéCES SONT CRITIQUES POUR LA SƒCURITƒ
DE FONCTIONNEMENT. NE REMPLACER CES COM-
POSANTS QUE PAR DES PIéCES SONY DONT LES
NUMƒROS SONT DONNƒS DANS CE MANUEL OU
DANS LES SUPPLƒMENTS PUBLIƒS PAR SONY.SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK ! OR DOTTED
LINE WITH MARK ! ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB-
LISHED BY SONY.
SECTION 1
SERVICING NOTES
IC101
S102
Notes on chip component replacement
¥ Never reuse a disconnected chip component.
¥ Notice that the minus side of a tantalum capacitor may be dam-
aged by heat.
Page 2
Ð 3 Ð
SECTION 2
GENERAL This section is extracted from
instruction manual.
