This is the 24 pages manual for sony tc 42 service manual.
Read or download the pdf for free.
If you want to contribute, please mail your pdfs to info@audioservicemanuals.com.
Power Requirements:
. Track System:
Ta pa:
Tape Speed:
Recording Time:
(with (2-120 (ape cassette)
Frequency Response:
\ Wow and Flutter:
Power Output:
Award Bias Fraquencv:
E Model
USA Model
Canada Model
AEP Model
CASSETTE-CDRDER
SPECIFICATiONS
DC 6 V with four penlighr batteries,
house hoid current with an ac adapter
[AC-9 (USA and Canada).
AC-4SGC (E and AEPH , rechargeabie
barterv pack (BF-23) or 12 V do with
SONY car battery curd (DOC-126)
Two'track mono
SONY rape cassette or equivalent
17/3 in: (4.8 cm/s)
2.0 hrs total
50 ~ 10,000 Hz
0.38 % (RMS) weighted
500 mW maximum
Approx. 41 kH:
Input: MIC input
impedance : low impeuance
Maximum sensitivity : 0.2 mV (-72 dB!
011mm: MONITOR output
Impedance : 80 or 10 k9 load
Outputlevel : 0_775V (0 dB]
with 10 k9 load
Speaker: 2 3% (70 mm)
Dynamic speaker
Voice coil impedance: 8 Q
Semiconductors: 1 FET, 13 xransistors and 8 diodes
Dimensions: 2(W) x 75mm) x 45/340)
(51 x 184 x 111 mm)
Weight: 2 lb 3 01 (0.98 kg) with four
penl ight batteries
,1 j"
SERVICE MANUAL}
Section
TABLE OF CONTENTS
Title Page
Specifications ............................. 1
OUTLINE
1-1V Servo Control Circuit Operation .................... 3
1-24 Auto Shut-off Mechanism Operation .................. 4
1-3. Block Diagram ............................. 5
1-4. External View ............................. 6
1-5. Internal View .............................. 6
DISASSEMBLY
2-1. Case (A) and (B) Removal ....................... 8
2-1 Case (C) Removal ...........................
2~3. Complete Circuit Board Removall
2-41 Motor Removal .......
26. Belt Removal ........
2-61 Midway Pulley Removal . , , .
2-7. Rewind Idler Slide Removal . 1
2-8. Fast Forward Plate Removal ,
2-9. Take-up Drum Removal ........................ 10
ADJUSTMENTS
3-1. Mechanical Adjustments ........................ 11
3-2, Electrical Adjustments/Measurements ................. 13
DIAGRAMS
4-1, Schematic Diagram ........................... 17
4A2. Mounting Diagrams ........................... 19
4-31Levchiagramslu.,....l.,l..l1..: ......... 21
EXPLODED VIEWS
5-1. Exploded View (1) ........................... 23
52. Exploded View (2) ........................... 25
5-3. Exploded View (3) ........................... 27
5-4, Packing ................................. 28
ELECTRICAL PARTS LIST ........................ 29
