SPECIFICATIONS

110, 127, 220 or 240V ac,
50/60Hz (AEP, UK model)

100, 110, 120, 127, 220, 240V ac,
50/60 Hz (E model)

Povver Consumption: 8 W

48 cm/s (17/3 ips)

Power Requirements:

Tape Speed:
Fast Forward and

Rewind Time: Approx. 90 sec. (by 060)

4-track 2-channel stereo
105 kHz

DOLBY. NR OFF
With FerriChrome Cassette
54 dB at peak level (NAB)
48 dB (DIN)
With chromium dioxide cassette
54dB at peak level (NAB)
With regular cassette
SZdB at peak level (NAB)
DOLBY' NFI ON
Improved by 5:13 at 1 kHz, 10dB
above 5 kHz

1.7%

DOLBY' NFI OFF
With Fern-Chrome Cassette and
chromium dioxide cassette
30-16,000Hz (NAB)
50-15,000Hz :3dB (NAB)
40-15,000Hz (DIN)

Recording System:
Record Bias Frequency:

Signal-to-Noise Ratio:

Frequency Response:

~Dolby' and lire double-D symbol are lite trade marks
0( Dolby Laboratory lnc Norse reduction system
rnanuluclured under license from Dulby Laboratory Inc

Wow and Flutter:

inputs:

Outputs:

REC/PB:

Dimensions:

Weight:

With regular cassette
30-14,000 HZ (NAB)
40-12000 Hz (DIN)

0,09% WRMS (NAB)
10.2% (DIN)

MIC (phone iack)
sensitivity 0.2mV (-72dB)
for low-impedance microphones
LINE lN (phone jack)
sensitivity 0.06V (-22dB)
input impedance more than 100 kn
LINE OUT (phone jack) . 2
output level 0.435V (-5 dB)
at load impedance 100 km
suitable load impedance more than
10 kn
HEADPHONES (binaural jack) ......... 1
suitable load impedance 8!!

Input impedance less than 10 km
Output impedance less than 10 k0

Approx. 390 (W) x 150 (h) x 295 (d) mm
15% (W) x 5% (hlx 115/5 (:1) inches
including projecting parts and controls

Approx. 6.3 kg (13lb1502)

0 dB .775 V
