Front Panel
SECTION 1
GENERAL
1 MOVIE button
2 MUSIC button
3 GAME button
4 PLACE button
5 P FILE button
6 EFFECT ON/OFF button
7 OPEN/CLOSE button
8 TUNER BAND button
9 STEREO/MONO button
q; MEMORY button
qa KARAOKE PON/MIX button
qs MIC LEVEL/ECHO VOL dial
qd MIX MIC1 jack
qf GROOVE button
qg VOLUME dial
qh M + button
qj ENTER/NEXT button
qk MULTI JOG STATION dialql m Ð button
w; NON-STOP button
wa EDIT button
ws FLASH button
wd PLAY MODE button
wf REPEAT button
wg PHONES jack
wh LOOP button
wj CLOCK/TIMER SET button
wk TIMER SELECT button
wl FUNCTION button
e; PROLOGIC button
ea DSP button
es DBFB button
ed DISPLAY/DEMO button
ef I/1 (POWER) button
eg MIX MIC2 jack
eh KEY CONTROL (#)
ej KEY CONTROL (2)
