Page 2

STR-DE497 P/ K4800 P/ K5800P

Outputs (Analog)

MD/lAIE (OUT). Voltage; 800 mv
VIDEO 1 Impedance: 10 kllonhms
(AUDIO OUT)

SUB WOOFER Voltage; 2 v

Impedance: 1 kiloohms

Reproductlon frequency range:
28 , 20.000 Hz

Tone
Gam levels :6 dB, 1 dB ep

* Models of area code AEP, UK only.

FM iuner section

Tunlng range 87.5 , 103.0 MHz
Antenna FM wire antenna
Antenna iermillals 75 ohms. unbalanced
Inlermediale frequency 10.7 MHz

AM tuner section

Tuning range
Models of area code US. CND
wtth 1011-1; tunlug scale: 530 , 1,7l0 kHz 1)
w1th 971(1-12 ilinIng scale: 531 , 1,710 kHz 1»

Models of area code AEP. UK
Willi 97kHz inning scale: 53] r 1,602 kHz

Antenna Loop antenna
Intermediate frequency 450 kHz

3) You can change the AM tunlnp scale to 9 kHz or 10 kHz.
After tuning In any AM statton, turn off the receiver. Whlle
holdlng down PRESET TUNING + or TUNING +, press
I/L'). All preset stations will be erased when you change
the tunlng scale. To reser the scale to 10 kHz (or 9 kHz),
repear (he procedure.

Video section
Inputs/Outputs
Vldeo: 1 Vprp. 75 ohms

General
Power requiremenis

Area code Po requirements
US, CND 120VAC, 601-12
AEP, UK 230 v A

Power consumptlon

Area code Power consumption
US (ST 4800P) 165 w
US (STRVKSSODP) 180 w
CND 225 VA
AEP. UK 150 w

Power consumptlon (durtng standby mode)
0.3 w

Dhnenslons (w/h/d) (Approx)
430 x145 x 310.5 mm
(17 x 5 (six x 11 7/1 inches)
tncludlng projectlng parts
and controls

Mass (Approx) 5.5 kg (14 lb 6 oz)

DesIgII and speclttcattons are subject to change
wirhom norlee.

- Abbrevimion
CND : Canadian model
