2 SS-XG55 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 1X-4953-449-1 PANEL ASSY, FRONT 24-999-101-01 SCREW, HEXAGON HOLE TAPPING 34-231-621-01 TW HORN 61-537-332-11 TERMINAL BOARD 74-232-311-01 PACKING (DUCT) 94-874-614-31 SCREW (3.5X12), TAPPING EXPLODED VIEW AND PARTS LIST NOTE: -The mechanical parts with no reference num- ber in the exploded views are not supplied. 10 4-227-036-01 BRACKET SP1 1-529-959-21 SPEAKER (16cm) SP2 1-529-657-11 SPEAKER (16cm) SP3 1-529-960-11 SPEAKER (2.5cm) #1 7-685-661-19 SCREW+BVTP 4x12 TYPE2N-S 1 23 #1 #1 7 SP2SP3 SP1not supplied not supplied not supplied not supplied not supplied 10 9 9

Page 2

3 SS-XG55 MEMO
