Sony ss xb 5 a service manual

Page 1

SS-XB5A Ñ 2 Ñ Sony Corporation Home A&V Products Company 97K7554-1 Printed in Germany © 1997. 11 Published by General Engineering Dept. (Shibaura) 9-922-742-11 1. EXPLODED VIEW AND PARTS LIST Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 3-859-644-11 INSTRUCTION MANUAL (ENGLISH,FRENCH,SPANISH,PORTUGUESE ,GERMAN,DUTCH,ITALIAN,SWEDISH,DANISH ,FINNISH,RUSSIAN,POLISH,CZECH ,HUNGARIAN,GREEK,TURKISH) 1 X-4948-423-1 GRILLE FRAME ASSY 2 4-960-363-01 SCREW P 3.5 X 16 3 X-4948-422-1 SPEAKER (3 WAY) ASSY 4 4-990-484-01 SPEAKER CABINET 5 4-990-487-01 DUCT 12 2 3 54 not supplied
