Sony ss srf 1 service manual

This is the 4 pages manual for sony ss srf 1 service manual.
Read or download the pdf for free. If you want to contribute, please mail your pdfs to info@audioservicemanuals.com.

Page: 1 / 4
left right
sony ss srf 1 service manual

Extracted text from sony ss srf 1 service manual (Ocr-read)

Page 1

2 SS-SRF1/SRF1A EXPLODED VIEW AND PARTS LIST Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 1 X-4949-452-A PANEL ASSY, FRONT * 2 X-4949-775-1 CABINET ASSY, SPEAKER 3 7-685-659-79 SCREW +BVTP 4X8, TYPE2 4 7-685-661-79 SCREW +BVTP 4X12, TYPE2 5 4-929-125-01 SCREW (M4X6), TAPPING 6 1-537-775-11 TERMINAL BOARD SP1 1-505-895-11 SPEAKER (10cm) ACCESSORIES & PACKING MATERIALS ******************************* 1-769-433-11 CORD, SPEAKER 3-862-251-11 MANUAL INSTRUCTION (ENGLISH/FRENCH/ SPANISH/GERMAN/DUTCH/SWEDISH/ITALIAN/PORTUGUESE/CHINESE) (SS-SRF1A) NOTE: - Items marked * are not stocked since theyare seldom required for routine service. Some delay should be anticipated when ordering these items. SP1 1 3 4 2 5 6 5 Ver 1.1 2001. 04

Page 2

3 SS-SRF1/SRF1A MEMO
