2 Ref. No. Part No. Description Remark -“-“-“-“-“-“-“ -“-“-“-“-“-“-“ -“-“-“-“-“-“-“-“-“ -“-“-“-“-“-“ EXPLODED VIEW AND PARTS LIST NOTE:- The mechanical parts with no reference num- ber in the exploded views are not supplied. 1 A-4412-675-A FRONT PANEL ASSY 2 4-874-614-21 SCREW (4) (3X.5X14), TAPPING 3 4-942-029-01 PACKING 4 4-986-971-01 SCREW (3.5) 5 A-4412-676-A SPEAKER CABINET ASSY 6 1-537-332-11 TERMINAL BOARD SP1 1-529-687-11 SPEAKER (4CM) SP2 1-529-925-11 LOUDSPEAKER(15CM)(RS80V) SP2 1-529-948-11 LOUD SPEAKER (15CM) (RS80) SS-RS80/RS80V SP1 SP2 12 23 4 56

Page 2

3 SS-RS80/RS80V MEMO
