sony ss rs 70 v service manual

Extracted text from sony ss rs 70 v service manual (Ocr-read)

Page 1

2 Ref. No. Part No. Description Remark -“-“-“-“-“-“-“ -“-“-“-“-“-“-“ -“-“-“-“-“-“-“-“-“ -“-“-“-“-“-“ EXPLODED VIEW AND PARTS LIST NOTE:- The mechanical parts with no reference num- ber in the exploded views are not supplied. 1 A-4412-673-A FRONT PANEL ASSY 2 4-874-614-21 SCREW (4) (3.5X14), TAPPING 3 A-4412-674-A SPEAKER CABINET (L) ASSY 3 A-4412-913-A SPEAKER CABINET (R) ASSY 4 4-942-029-01 PACKING SP101 1-529-926-11 LOUD SPEAKER (13cm)(SS-RS70V) SP101 1-529-943-11 LOUD SPEAKER (13cm)(SS-RS70) SP102 1-529-944-11 LOUD SPEAKER (4cm) SS-RS70/RS70V SP101 SP102 1 22 2 3 4

Page 2

3 SS-RS70/RS70V MEMO
