Page 1

2 Ref. No. Part No. Description Remark -“-“-“-“-“-“-“ -“-“-“-“-“-“-“ -“-“-“-“-“-“-“-“-“ -“-“-“-“-“-“ EXPLODED VIEW AND PARTS LIST NOTE:- The mechanical parts with no reference num- ber in the exploded views are not supplied. 1 X-4953-587-1 FRAME ASSY, GRILLE 2 4-934-223-01 SCREW (4X20), TAPPING 3 4-210-830-01 CATCHER 4 4-932-425-01 SCREW (3.5X20) 5 A-2004-826-A CABINET ASSY 6 1-537-332-11 TERMINAL BOARD SP1 1-544-777-11 SPEAKER (13CM) SP2 1-544-778-11 SPEAKER (2.5CM) SS-MB100H 12 23 3 4 45 SP1 SP2 6 ACCESSORIES & PACKING MATERIALS ******************************* 1-769-433-11 CORD, SPEAKER (2.5M) 4-233-921-11MANUAL, INSTRUCTION (ENGLISH, FRENCH, SPANISH, PORTUGUESE, TRADITIONAL CHINESE, SYMPLIFIED CHINESE) Ref. No. Part No. Description Remark -“-“-“-“-“-“-“ -“-“-“-“-“-“-“ -“-“-“-“-“-“-“-“-“ -“-“-“-“-“-“
