NOTE:
¥ The mechanical parts with no reference
number in the exploded views are not
supplied.
¥ Items marked "*" are not stocked since
they are seldom required for routine
service. Some delay should be anticipated
when ordering these items.
1. EXPLODED VIEW AND PARTS LIST
Ref. No. Part No. Description Remark
1 4-968-202-01 SPEAKER CABINET
2 X-4944-569-1 GRILLE FRAME ASSY
3 1-537-529-11 TERMINAL BOARD
4 4-960-363-01 SCREW + P 3,5 X 16
SP1 1-504-233-11 SPEAKER (25 cm CONE)
SP2 1-504-234-11 SPEAKER (8 cm CONE)
SP3 1-504-232-11 SPEAKER (5 cm DOME) Ref. No. Part No. Description Remark
1-751-495-11 SPEAKER CORD
3-759-185-11 INSTRUCTION MANUAL
*4-968-203-01 CARTON
*4-968-206-01 POLYETHYLENE BAG
*4-968-204-01 CUSHION (B)
*4-968-205-01 CUSHION (T)
4
2
SP2SP3
4
4
SP1
3
1
