2 SS-CPX333 EXPLODED VIEW AND PARTS LIST NOTE: - Items marked * are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. - The mechanical parts with no reference number in the exploded views are not supplied. Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 1 4-874-614-11 SCREW (4) (3.5X14), TAPPING 2 4-932-425-21 SCREW (3.5X20) 3 X-4953-796-1 PANEL (L) ASSY, GRILLE 3 X-4953-797-1 PANEL (R) ASSY, GRILLE 4 4-912-253-01 CATCHER 14 3 25 not supplied not supplied not supplied not supplied 6 5 1-537-332-11 TERMINAL BOARD 6 A-2004-993-A SYSTEM (L) ASSY (AEP,UK) 6 A-2004-994-A SYSTEM (R) ASSY (AEP,UK) 6 A-2004-995-A SYSTEM (L) ASSY (AUS,HK,SP) 6 A-2004-996-A SYSTEM (R) ASSY (AUS,HK,SP) -Abbreviation AUS : Australian model HK : Hong Kong model SP : Singapore model

Page 2

3 SS-CPX333 MEMO
