2 SS-CPX22/NXM3 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks EXPLODED VIEWS NOTE: --XX, -X mean standardized parts, so they may have some difference from the original one. - Items marked * are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. - The mechanical parts with no reference number in the exploded views are not supplied. not supplied not supplied not supplied not supplied 1 3 3 2 3 2 4 R-CH 1 A-4713-853-A SYSTEM (R) ASSY 1 A-4713-854-A SYSTEM (L) ASSY 2 4-249-981-01 PIN, CATCHER 3 4-235-903-02 SCREW (3.5X20) 4 X-4956-273-1 TWEETER ASSY
