Page 1
Ð 2 Ð
TABLE OF CONTENTS
Specifications ........................................................................... 1
1. SERVICING NOTE ....................................................... 3
2. GENERAL
Location and Function of Controls .................................... 4
3. DISASSEMBLY
3-1. Neck Band Removal ................................................... 5
3-2. Driver (Headphone) (R) Removal .............................. 5
3-3. Driver (Headphone) (L) Removal .............................. 5
3-4. Main Board Removal ................................................. 6
3-5. Audio Board Removal ................................................ 6
4. GEAR (TUNING CAPACITOR)
INSTALLATION
........................................................... 7
5. ELECTRICAL ADJUSTMENTS .............................. 8
6. DIAGRAMS
6-1. Printed Wiring Boards ............................................... 11
6-2. Schematic Diagram ................................................... 13
7. EXPLODED VIEW ..................................................... 17
8. ELECTRICAL PARTS LIST .................................... 18
Notes on chip component replacement
¥ Never reuse a disconnected chip component.
¥ Notice that the minus side of a tantalum capacitor may be dam-
aged by heat.
Page 2
Ð 3 Ð
SECTION 1
SERVICE NOTE
(Caution on Service)
Drip-proof freatment
Be sure to execute the following, when the cabinet is removed
during service.
Applicator SONY Grease SGL-601 (7-651-000-10) and apply
Silicone KE-490RTV (7-322-065-19) to the hatched portion
shown in figure using an applicator, etc.
KE-490RTV
SGL-601
SGL-601
KE-490RTVKnob
(power)Knob (VOL)
Lever Cabinet (rear) R
Knob
(power)
Cabinet (rear) L
Cabinet (rear) R LeverPoly-slider Washer
Knob
(tune)Cabinet (rear) L
