SECTION 2
DISASSEMBLY
Note : Follow the disassembly procedure in the numerical order given.
2-1. CABINET (LOWER)
2-2. PANEL, FLONT
r The equipment can be removed using the following procedure.
Cabinet (Lower) Set
Panel, Front Main board
3 Cabinet (Lower )
Cabinet (Upper)
2 Screws (P 2.6x20)
1 Screws (P 2.6x20)
Cabinet (Upper)
1 Screws (P 2.6x8)
2 Panel, Front
2-3. MAIN BOARD
Cabinet (Upper )
1 Screws (P 2.6x8)
2 Main board
