Page 1
- 2 -
Notes on chip component replacement
- Never reuse a disconnected chip component.
- Notice that the minus side of a tantalum capacitor may be
damaged by heat.
Flexible Circuit Board Repairing
- Keep the temperature of soldering iron around 270ËšC
during repairing.
- Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
- Be careful not to apply force on the conductor when soldering
or unsoldering.
1. GENERAL ······································································ 2
2. DISASSEMBLY
2-1. Case (Lower) ···································································· 17
2-2. Main Board ······································································· 17
3. TEST MODE ································································ 18
4. DIAGRAMS
4-1. IC Pin Function ································································ 20
4-2. Printed Wiring Board -“Main Section -“ ···························· 21
4-3. Schematic Diagram -“Main Section -“ ······························· 23
5. EXPLODED VIEW ····················································· 25
6. ELECTRICAL PARTS LIST ··································· 26
TABLE OF CONTENTS
SECTION 1
GENERAL
This section is extracted
from instruction manual.
