- 2 - Power back -up Back-up duration: 0 min 5 °C to 35 °C (41 °F to 95 °F) Storage tem perature -ˆ’20 °C to 60 °C ( -ˆ’4°F to 140 °F) Opera ting humidity 25% to 80% Dime nsions including pro jecting parts a nd controls (w/h/d) Approx. 430 × 85 × 334 mm ( Approx. 17 × 3 × 13 1/4 inches) Supplied accessories Remote commander (remote) (1) S ize AA (R6) batteries (2) Antenna cable (1) Audio/video cord (1) Design and specifications are subject to change without notice. General Power requirements 120 V AC, 60 Hz Power c onsumption 40 W Mass Approx. 4.9 kg (Approx. 10.8 lbs) Operating temperature DIGITA L AUDIO OUT OPTICAL, Optical output jack COAXIAL, phono jack Output signal: 0.5 Vp -p, 75 ohms CO MPONENT V IDEO OUT (Y, P B, P R) Ph ono jack Y: 1 . 0 Vp -p/P B, PR: 0 . 7 Vp -p, 75 ohms S VID EO OUT 4-pin, mini-DIN jack Y: 1.0 Vp -p, unbalanced, sync nega tive C: 0. 286 Vp -p, load impedanc e 75 ohms -ˆ’ 18 dBm (wave length: 660 nm) 3/8
