Page 1
- 2 -
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH
MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS
LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE
COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS
APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS
PUBLISHED BY SONY.
1. Check the area of your repair for unsoldered or poorly-soldered
connections. Check the entire board surface for solder splashes
and bridges.
2. Check the interboard wiring to ensure that no wires are
"pinched" or contact high-wattage resistors.
3. Look for unauthorized replacement parts, particularly
transistors, that were installed during a previous repair. Point
them out to the customer and recommend their replacement.4. Look for parts which, through functioning, show obvious signs
of deterioration. Point them out to the customer and
recommend their replacement.
5. Check the B+ voltage to see it is at the values specified.
6. Flexible Circuit Board Repairing
-Keep the temperature of the soldering iron around 270˚C
during repairing.
-Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
-Be careful not to apply force on the conductor when soldering
or unsoldering.
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer.
CAUTION
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous radiation
exposure.
WARNING!!
WHEN SERVICING, DO NOT APPROACH THE LASER EXIT WITH
THE EYE TOO CLOSELY. IN CASE IT IS NECESSARY TO
CONFIRM LASER BEAM EMISSION, BE SURE TO OBSERVE
FROM A DISTANCE OF MORE THAN 25 cm FROM THE SURFACE
OF THE OBJECTIVE LENS ON THE OPTICAL PICK-UP BLOCK.
CAUTION:
The use of optical instrument with this product will increase eye
hazard.
Unleaded solder
Boards requiring use of unleaded solder are printed with the lead-
free mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with
the lead free mark due to their particular size.)
: LEAD FREE MARK
Unleaded solder has the following characteristics.
-Unleaded solder melts at a temperature about 40°C higher than
ordinary solder.
Ordinary soldering irons can be used but the iron tip has to be
applied to the solder joint for a slightly longer time.
Soldering irons using a temperature regulator should be set to
about 350°C.
Caution: The printed pattern (copper foil) may peel away if the
heated tip is applied for too long, so be careful!
-Strong viscosity
Unleaded solder is more viscous (sticky, less prone to flow) than
ordinary solder so use caution not to let solder bridges occur such
as on IC pins, etc.
-Usable with ordinary solder
It is best to use only unleaded solder but unleaded solder may
also be added to ordinary solder.
Page 2
- 3 -
TABLE OF CONTENTS
SERVICE NOTE
1. DISK REMOVAL PROCEDURE IF THE TRAY
CANNOT BE EJECTED (FORCED EJECTION)············5
1. GENERAL
WARNING············································································1-1
Precautions·············································································1-1
Quick Guide to Disc Types····················································1-1
Hookups and Settings································································1-2
Hooking Up the Recorder······················································1-2
Step 1: Connecting the Aerial Cable······································1-3
Step 2: Connecting the Video Cords······································1-3
Step 3: Connecting the Audio Cords·····································1-4
Step 4: Connecting the Mains Lead·······································1-4
Step 5: Preparing the Remote················································1-4
Step 6: Easy Setup·································································1-5
Connecting a VCR or Similar Device····································1-5
Connecting to a Satellite or Digital Tuner·····························1-6
Connecting a PAY-TV/Canal Plus Analogue Decoder··········1-6
Eight Basic Operations - Getting to Know Your DVD
Recorder··········································································1-7
1. Inserting a Disc··································································1-7
2. Recording a Programme····················································1-7
3. Playing the Recorded Programme (Title List)···················1-8
4. Displaying the Playing/Remaining Time and Play
Information········································································1-8
5. Changing the Name of a Recorded Programme················1-9
6. Labelling and Protecting a Disc·········································1-9
7. Playing the Disc on Other DVD Equipment (Finalise)·····1-9
8. Reformatting a disc··························································1-10
Timer Recording······································································1-10
Before Recording·································································1-10
Timer Recording (Standard/ShowView)······························1-11
Checking/Changing/Cancelling Timer Settings
(Timer List)······································································1-12
Recording From Connected Equipment······························1-12
Playback··················································································1-13
Playing·················································································1-13
Searching for a Title/Chapter/Track, etc.·····························1-14
Playing MP3 Audio Tracks, JPEG Image Files, or DivX
®
Video Files·······································································1-15
Erasing and Editing·································································1-16
Before Editing······································································1-16
Erasing and Editing a Title··················································1-16
Creating and Editing a Playlist (RDR-GX220 only)···········1-16
Settings and Adjustments························································1-17
Aerial Reception and Language Settings (Basic)················1-17
Video Settings (Video)·························································1-19
Audio Settings (Audio)························································1-19
Recording Settings (Recording)··········································1-20
Disc Settings (DVD)····························································1-20
Remote Control Settings/Factory Settings (Others)············1-20
Easy Setup (Resetting the Recorder)···································1-21
Additional Information····························································1-21
Troubleshooting···································································1-21
Self-diagnosis Function (When letters/numbers appear in the
display)·············································································1-22
Notes About This Recorder·················································1-22
Specifications·······································································1-23
Guide to Parts and Controls·················································1-23
Language Code List·····························································1-24
2. DISASSEMBLY
2-1. UPPER CASE·································································2-2
2-2. TRAY COVER ASSEMBLY··········································2-2
2-3. FRONT PANEL SECTION·············································2-3
2-4. FL-157 BOARD, FR-238 BOARD·································2-32-5. DVD DRIVE···································································2-4
2-6. RD-060 BOARD·····························································2-4
2-7. AV-101 BOARD······························································2-5
2-8. POWER BLOCK·····························································2-6
2-9. D.C. FAN·········································································2-6
2-10. CIRCUIT BOARDS LOCATION···································2-7
3. BLOCK DIAGRAMS
3-1. OVERALL BLOCK DIAGRAM····································3-1
3-2. AV-101 BLOCK DIAGRAM··········································3-3
3-3. RD-060 BLOCK DIAGRAM··········································3-5
3-4. POWER BLOCK DIAGRAM·········································3-7
4. SCHEMATIC DIAGRAMS AND
PRINTED WIRING BOARDS
4-1. SCHEMATIC DIAGRAMS············································4-1
WAVEFORMS································································4-2
- AV-101 (1/7) (POWER SUPPLY)
SCHEMATIC DIAGRAM······························4-3
- AV-101 (2/7) (AUDIO AMP)
SCHEMATIC DIAGRAM······························4-5
- AV-101 (3/7) (AUDIO OUT)
SCHEMATIC DIAGRAM······························4-7
- AV-101 (4/7) (TUNER)
SCHEMATIC DIAGRAM······························4-9
- AV-101 (5/7) (IT CONTROL)
SCHEMATIC DIAGRAM····························4-11
- AV-101 (6/7) (VIDEO AMP/SELECTOR)
SCHEMATIC DIAGRAM····························4-13
- AV-101 (7/7) (AUDIO/VIDEO SELECTOR)
SCHEMATIC DIAGRAM····························4-15
- FL-157 (POWER SWITCH)
SCHEMATIC DIAGRAM····························4-17
- FR-238 (FLUORESCENT TUBE/LED DRIVE, L2 IN)
SCHEMATIC DIAGRAM····························4-19
- RD-060 (1/5) (RISM3)
SCHEMATIC DIAGRAM····························4-21
- RD-060 (2/5) (VIDEO DECODER)
SCHEMATIC DIAGRAM····························4-23
- RD-060 (3/5) (A/V INTERFACE)
SCHEMATIC DIAGRAM····························4-25
- RD-060 (4/5) (AUDIO DAC/ADC)
SCHEMATIC DIAGRAM····························4-27
- RD-060 (5/5) (VIDEO DECODER)
SCHEMATIC DIAGRAM····························4-29
SWITCHING REGULATOR (SRV-1855EK)
SCHEMATIC DIAGRAM····························4-31
4-2. PRINTED WIRING BOARDS
- RD-060 (RISM3, VDEC, A/V INTERFACE,
AUDIO DAC/ADC)
PRINTED WIRING BOARD·······················4-33
5. IC PIN FUNCTION DESCRIPTION
5-1. IT CONTROL IC
(IC603: M306H5FGFP (AV-101 BOARD))···················5-1
5-2. MAIN CONTROL IC
(IC103: R8A34012BG (RD-060 BOARD))····················5-4
6. SERVICE MODE
6-1. Check Item······································································6-1
6-2. Screen Transition in the Service Mode····························6-2
6-3. Items and Description of Service Mode Menu················6-3
6-4. Device Check Menu (Diagnostic Test)····························6-3
7. ADJUSTMENT
7-1. Video System Adjustment···············································7-1
1. Video Output Level Check··············································7-1
